EAN: 5060514912485
OUTDOOR PANEL
AV-01D

Device description

This individual call panel is very different for the better in design and
characteristics from ordinary panels installed in houses and apartments.
Thanks to IP65 protection, the panel can be easily installed on the street
without fear of heavy rain and other "joys" of nature.
Appearance

Main feature

Panel type: Individual.
Display: No.
Keypad: No.
Camera: 1/4", adjustable camera angle by 15°.
Angle: 90° horizontal x 56° vertical.
Resolution: 1 Мp.
Output video: HD (1280 × 720), H.264 Main Profile.
Night backlight: 6 LEDs.
Light sensitivity: 0,01 LuX.
Protection class: IP65.
Working temperature: -40 — +65 °С.
Power consumption: 5,5 W, in standby — 2,5 W.
Power supply: +12 V DC, PoE.
Body: Metallic.
Colors: Titanium gray.
Dimensions for installation: 104 × 180 × 60 mm.
Size of the panel: 115 × 190 × 45 mm.
Installation: Flush, surface with BR-AV bracket.
1
2
3
4
5
6
7
1 - Light sensor. 5
2 - Microphone. 6
3 - Camera. 7
4 - Backlight.
Full User Manual
wiki.bas-ip.com
- Call button.
- Place for name label.
- Loudspeaker.
