1 Hardware
1.1 Sample Distribution Set Contents
The contents of the conga-QMX8-X sample distribution set are listed
below:
Part # Rev. Name
007005 B.5 conga-QEVAL/Qseven
2.0 ARM
016500 or Y.1 conga-QMX8-X/
016503 or QXP-4G eMMC16 or
016513 QXP-2G eMMC16 or
i-QXP-2G eMMC16
016453 X.1 conga-QMX8/HSP-T
011115 B.0 conga-LDVI/EPI
033331 A cab-LVDV-DAT-34-15
052147 A cab-LVDV-PWR-10-15
48000023 A RS232 adapter cable
10000285 A MicroSDHC-Card UHS-I
N/A 1.1 Quick Start Guide
1.2 conga-QMX8-X
The conga-QMX8-X (Revision Y.1) included in this sample distribution
set is a Qseven 2.0 engineering sample module featuring the NXP i.MX
8QuadXPlus applications processor, 16 GB HS400 onboard eMMC,
and 4GB or 2 GB LPDDR4 onboard memory.
For information about the Mass Production (MP) variants, refer to the
datasheet available at www.congatec.com.
Copyright © 2019 congatec AG
Description Qty
Evaluation carrier board for standard 1
Qseven modules based on Qseven
Specification 2.0
Qseven 2.0 engineering sample module 1
with NXP i.MX 8QuadXPlus applications
processor, 16 GB onboard HS400
eMMC, and 4GB or 2GB LPDDR4.
Standard heatspreader for Qseven 1
module conga-QMX8 with IHS CPU. All
stand-offs are bore hole 2.7 mm.
LVDS to DVI converter board for digital 1
flat panels with onboard EEPROM.
15 cm data cable LVDS to DVI adapter 1
15 cm power cable LVDS to DVI adapter 1
MOLEX 6-pin PicoBlade to 2x D-SUB 9 1
adapter
Kingston industrial SDCIT/EU Class 10 1
8 GB microSD card with SD card adapter
and preinstalled image.
conga-QMX8-X Sample Distribution Set 1
Quick Start Guide
1.2.1

Pinout Description

The conga-QMX8-X pinout description is available at the link below.
The pinout description lists which signals of the NXP i.MX 8QuadXPlus
applications processor are routed to the Qseven connector.
https://git.congatec.com/arm-nxp/imx8-family/doc/cgtimx8_pinlist/-/raw/
cgtqx8x_pinlist/cgtqx8x_pin_connection.xlsx
1.3 conga-QEVAL/Qseven 2.0 ARM
The conga-QEVAL/Qseven 2.0 ARM included in this sample distribution
set is an evaluation carrier board based on the Qseven Specification 2.0.
For information about the conga-QEVAL/Qseven 2.0 ARM, refer to the
User's Guide available at www.congatec.com.
