Philio PSR07 Manual

PSR07 Smart Color Button
This device is a multiple functions button switch. It is able to switch
the appliances on/off or adjust the percentage of dimmer. It can also
work as a timer. The well designed wall bracket and magnetic back
let the switch can be fixed on the wall. This product can be included
and operated in any Z-Wave
certified devices from other manufacturers and/or other applications.
Note:
Please provide a 5 DVC voltage through Micro USB Port to
wake the device up before the first using.
The rotation function and timer functions work only when the device
is fitted upright or stick on the wall or the device will only work as an
on/off switch when fitted horizontal.
TM
network with other Z-Wave

Z-Wave Network Setting Up

In the first time, add the device into the Z-Wave
sure the primary controller is in the add mode. And then power on
the device through micro USB. The device will auto start the NWI
(Network Wide Inclusion). Red LED will flash every second and
continue 30 seconds. And it should be included in 5 seconds. Red
LED will light ON one second. Rotating to area A(shown in Fig. 1)
and touch 3 times can abort NWI mode.
There is a touch button on the front side. The button carries out
manual inclusion, exclusion and reset to default.
1. Include: Pointing the arrowhead to area A first (shown in Fig. 1).
Pressing the button three times within 1.5 seconds. The red LED
will light up for 1 second if succeed.
2. Exclude: Pointing the arrowhead to area A first. Pressing the
button three times within 1.5 seconds.
Reset to default: Pointing the arrowhead to area A first. Pressing
3.
button four times within 2 seconds and hold at fourth. The red
LED will light for 3 seconds, release the button within 2 seconds
while the LED goes out. The LED will flash for 1 second if reset
succeed, or LED will flash once
Notice: Including a node ID allocated by Z-Wave
"Add" or "Inclusion". Excluding a node ID allocated by Z-Wave
TM
Controller means "Remove" or "Exclusion".

Function

This device can control dimmers in group 2: Dimmer and Binary
Switch. Point the arrowhead to area A(shown in Fig. 1) then hold the
button, release after the red LED go out. The device can switch to
Binary Switch mode automatically when fitting horizontal.
TM
network. Make
.
TM
Controller means
TM
