NetVanta 1234/1238
Layer 2 Fast Ethernet Switches
Product Specifications

Physical Interface

Ethernet Ports
NetVanta
1234: 24 10/100Base-T
®
■
NetVanta 1238: 48 10/100Base-T
■
Two 10/100/1000Base-T
■
Two Combo 10/100/1000Base-T/SFP
■
Auto Rate/Duplex/MDI/MDI-X
■
Console Port
DB-9, RS-232
■
Switching Performance
Non-blocking
■
8,000 MAC Addresses
■
Maximum Forwarding Bandwidth
NetVanta 1234: 12.8 Gbps
■
NetVanta 1238: 17.6 Gbps
■
Diagnostics
Port Mirroring LLDP (802.1AB)
■ ■
LLDP-MED Ping
■ ■
Cable Diagnostics
■
Front Panel Status LEDs
Power Status
■
LAN: Link, Activity
■
Port Statistics
Number of TX/RX Frames
■
Number of Collisions
■
Number of Errors
■
Spanning Tree Support
802.1D Spanning Tree
■
802.1w Rapid Spanning Tree
■

Link Aggregation

802.3ad Link Aggregation
■
Support for Six Trunk Groups
■
Trunk groups consist of up to eight
■
access ports or two uplink ports
Quality of Service (QoS)
802.1p and DiffServ
■
Four output queues per egress port
■
Weighted Round Robin (WRR)
■

VLAN Support

Port-based VLANs
■
802.1Q Tagged Trunked VLANs
■
Support for up to 255 Active VLANs
■
ADTRAN believes the information in this publication to be accurate as of publication date, and is not responsible for error. Specifications
subject to change without notice. ADTRAN and NetVanta are registered trademarks of ADTRAN, Inc. and its affiliates in various countries.
All other trademarks mentioned in this document are the property of their respective owners. The NetVanta Limited Lifetime Warranty
applies to select products. This limited warranty is applicable in all countries where ADTRAN products are sold and where ADTRAN and
its authorized service providers offer warranty service. For complete warranty information, visit www.adtran.com/warranty
ADTRAN products may be subject to U.S. export controls and other trade restrictions. Any export, re-export, or transfer of the products
contrary to law is prohibited. For more information regarding ADTRAN's export license, please visit www.adtran.com/exportlicense
Wi-Fi Controller
®
Controls up to 24 NetVanta Wireless Access Points
■

Storm Control

Broadcast, Unicast, and Multicast
■
Administration
Familiar Command Line Interface (CLI)
■
Web-based GUI
■
n-Command Support
®
■
SNMP v3
■
Network Access Control
Port Authentication (802.1x)
■
Environment
Operating Temperature: 0° to 50 °C (32° to 122 °F)
■
Storage Temperature: -20° to 70 °C (-4° to 158 °F)
■
Relative Humidity: Up to 95%, Non-condensing
■
Physical
Chassis: 1U, 19" Rackmountable Metal Enclosure
■
NetVanta 1234
■
Dimensions: 1.7" H, 17.4" W, 8.1" D
l
Weight: 5 lbs
l
Power: 25 Watts
l
NetVanta 1238
■
Dimensions: 1.7" H, 17.4" W, 12.2" D
l
Weight: 8.5 lbs
l
Power: 40 Watts
l
AC Power: 100–250 VAC, 50/60 Hz
■

Agency Approvals

FCC Part 15 Class A, UL 1950/CSA, CE Mark, C-tick
■

Ordering Information

Equipment
NetVanta 1234
NetVanta 1238
NetVanta 1000BaseSX SFP (LC Connectors) 1200480E1
NetVanta 1000BaseLX SFP (LC Connectors) 1200481E1
SYSLOG Logging
■
Email Alerts (SMTP)
■
TCL Scripting
■
Part #
1700594G1
1700598G1
NetVanta 1234
NetVanta 1238
