Curt Manufacturing Rebellion XD Installation Manual

Curt Manufacturing Rebellion XD Installation Manual

Adjustable cushion hitch with dual ball

Advertisement

Quick Links

INSTALLATION MANUAL
Level of Difficulty
Easy
Weight Capacity
Gross trailer weight (GTW)
Tongue weight (TW)
Parts List
Item Qty Description
1
1
Adjustable shank
2
1
Trailer ball platform
3
2
Pin
4
2
Clip
Hitch pin and clip not included
Tools Required
None
Maintenance
Mild automotive detergent may be used to
clean the product. Do not use dish detergent,
abrasive cleaners, abrasive pads, wire
brushes or other similar products that
may damage the finish.
Apply grease to the zerk located on the back
of the shank assembly prior to each use to
ensure quiet and trouble-free operation.
CURTMFG.COM
NEED ASSISTANCE?
DANGER
Cannot be used in the rise position.
WARNING
15,000 lbs.
Never exceed the vehicle manufacturer's recommended towing capacity. The ratings of
the mount system are intended to represent the capability of the product and in no way
1,500 lbs.
reflect the ratings or capacity of the towing system it is being used with. The consumer
or operator are strongly advised to learn the ratings of the various components of the
towing system and never exceed the limits of the lowest rated component being used.
Use of any pin other than that of the mount system manufacturer
could be a serious safety hazard and will void the warranty.
Check for proper clearance of the trailer coupler to the tongue of the Rebellion XD when latched
on the ball. Some couplers may require a 1" rise ball to add clearance for maneuvering.
Never hook up trailer safety chains to the mount system. Ensure the safety
chains operate freely around the mount system and do not become entangled.
Product Photo
NOTICE
Before you begin installation, read all instructions thoroughly.
Prior to towing, ensure all fasteners are tight and all structural components are sound.
Using a torque wrench and 3/8" hex drive socket, torque hardware to 45-55 lb-ft.
Product Registration
CURT Group stands behind our products with industry-leading warranties.
Provide feedback and help us to improve our products by registering your purchase at:
warranty.curtgroup.com/surveys
877.287.8634
45949-INS-RF
PAGE 1
