You can change the name of the device that is displayed in the wBox
application. In addition, you can change the name and password of its
generated WiFi network. Remember that changing the network name or
password will disconnect the device immediately after you click the "Save"
button, so re-connect to the device using the newly assigned network name
and password.
You can add the controller to your home WiFi network to control it through
this home network or from anywhere in the World. To do this, in the "Connect"
settings section, select a network name from the list and press "Connect". If is
required, enter the WiFi network password. During the connection of the
controller to your home network, the phone / tablet may disconnected from
the network. In this case, you will need to reconnect your phone / tablet to the
controller network.
Please remember that in order to control the device outside the local WiFi
network, from anyplace in the World by using the wBox application, the
option "Remote access enabled" in the controller settings must be set to "Yes".
Once you've nished con guring the WiFi network, you can disconnect your
phone/tablet from the controller network and connect your mobile device
directly to your home WiFi network. The control from the wBox application
will work the same way as when the phone / tablet is connected to the
controller network. If the user leaves the local network, for example, leaving
home or using the mobile data, the wBox application will signal this state as
"Remote mode". In this case, the devices can be controlled, but for security
reasons settings are not available.
4
Return to the controller settings. In the "Access management" section, you can
also create accounts for the gate users. This provides additional protection for
access to the controller. If you create users, the option of adding a controller to
the wBox application and its control will be available only after entering the
correct login and password.
To add a new user, in the "Access management" section, press the "Add"
button and then ll in the new window the "User name" and "Password" elds
and press the "Save" button. If at least one user account is added, the
controller will require logging each time the controller is added to the wBox
application. Only after logging in the controller, it will be possible to control
the motor.

TECHNICAL SPECIFICATIONS

supply voltage
energy consumption
number of outputs
output type
maximum load
number of inputs
inputs type
voltage range
galvanic isolation
housing
protection level
ACCESS MANAGEMENT
12-24V AC / DC
< 1 W
2
open collector, pulse
20mA
2
logical
12 - 24V AC / DC
yes
plastic, covered with a polyurethane
composition not containing
halogens, self-extinguishing
for thermal class B (130°C)
54
IP
antenna output
antenna connector type
antenna
dimensions
transmission type
radio frequency
communication standard
mode
compatible devices
and systems

ADDITIONAL INFORMATION

SOFTWARE UPDATE

To update the software in the controller, connect it to your home WiFi network
(see "Access Point and WiFi Network Settings" section) which is connected to
the Internet. Go to "Settings" (icon at the top-right corner of the screen) and
click the "Get new rmware" button in the nal section on settings. Wait about
1 minute, do not close the interface and don't perform other actions. The
device will download the latest software. The software version number,
hardware version and device identi er can be read at the bottom of the
settings screen.
for more information visit our website
www.blebox.eu
or send us an email to: info@blebox.eu
support is available at support@blebox.eu
yes
RP-SMA
omnidirectional, 5dB gain
- included in the kit
50 x 92 x 28 mm (without antenna),
85 x 230 x 28 mm
(with the antenna located vertically),
antenna length 197 mm
bi-directional, encrypted
2.4 GHz
WiFi, compatible with WiFi, 802.11g
direct connection (as Access Point),
Wi-Fi connection via a standard router,
connection with access from any
location in the world (requires
only access to the Internet)
Apple iPhone, Apple iPad, iPad Mini,
Android, computers and
mobile devices supporting HTML5
