- Page 1 SSD7101A-1 Ultimate Acceleration Drive Quick Installation Guide V1.02...
- Page 2 • Windows 10 or later Linux Kernel 3.19 or later SSD7101A-1 Hardware Front View NVMe Drive Installation: Step 1. On the rear of the SSD7101A-1, remove the six screws that secure the unit’s front panel to the PCB.
- Page 3 After removing the screws, carefully remove the front panel from the SSD7101A-1. Step 2. These 4 screws are used to install the NVMe SSD’s.
- Page 4 Step 3. The SSDs should be installed from top to bottom. Remove the top screw. Step 4. Gently insert the SSD into the slot. Step 5. Refasten the screw to secure the SSD.
- Page 5 Repeat Steps 3 to 5 to install the remaining SSDs. Step 6. Replace the front panel after installing all SSDs Step 7. On the rear of the SSD7101A-1, refasten the 6 screws that were removed in step 1. Note: Please be sure to connect NVMe before using the product to...
- Page 6 After booting Windows, open Device Manager, and expand Disk drives. The installed NVMe Samsung SSD 960 should be displayed: Driver Installation Download the Windows driver package from the HighPoint website: https://highpoint-tech.com/USA_new/series-ssd7101a-1-download.ht Once downloaded, locate the folder you downloaded the driver to.
- Page 7 Rebooting. A HighPoint NVMe RAID Controller entry should be displayed under Storage Controllers: Installing the HighPoint RAID Manager The HighPoint NVMe Manager is used to configure and monitor the SSD7100 drive. Download the HighPoint RAID Manager software package from the HighPoint website: https://highpoint-tech.com/USA_new/series-ssd7101a-1-download.ht...
- Page 8 Customer Support If you encounter any problems while utilizing the SSD7100 drive, or have any questions about this or any other HighPoint Technologies, Inc. product, feel free to contact our Customer Support Department. Web Support: https://www.highpoint-tech.com/websupport/ HighPoint Technologies, Inc. websites: https://www.highpoint-tech.com...
