Check entire box and all packing materials for parts. Before beginning assembly, read the
instructions and identify parts using the fi gures and parts listed in this document.
It is critical that all parts be carefully inspected prior to installation. If any damage occurred in
transit, Aqua Creek Products, LLC must be notifi ed within three days of receipt of unit.
Proper installation cannot be overstressed, as an improper installation voids Aqua Creek's
warranty and may affect the safety of the user.
Copyright © 2019 Aqua Creek Products All Rights Reserved
400 LB. [181 kg] MAXIMUM WEIGHT CAPACITY
Lift safety can only be ensured if the lift is installed and
• NEVER permit children to play on or around the lift
• Do not allow children to use the lift without adult
supervision
• NEVER use the lift with a dry pool
READ CAREFULLY
EZ 2 Pool Lift
Manual
PART #: F-EZPL2-02
MANDATORY
LEAVE THIS MANUAL WITH LIFT OWNER
Read and follow all instructions.
operated according to these instructions.
1
Revised 11/1/19
Advertisement
Related Manuals for Aqua Creek Products EZ Series
Summary of Contents for Aqua Creek Products EZ Series
- Page 1 It is critical that all parts be carefully inspected prior to installation. If any damage occurred in transit, Aqua Creek Products, LLC must be notifi ed within three days of receipt of unit. Proper installation cannot be overstressed, as an improper installation voids Aqua Creek’s warranty and may affect the safety of the user.
- Page 2 CHAIN SET HANGER BAR SLING BARS ANCHOR (IF ORDERED WITH LIFT) 3/8” X 1 3/4” HEX BOLT 3/8” FLAT WASHER 3/8” NYLOCK NUT OWNERS MANUAL EZ RAM EZ SLING Copyright © 2019 Aqua Creek Products All Rights Reserved Revised 11/1/19...
- Page 3 Clean out the hole using a vaccum or compressed air. Check that the hole is deep enough to allow the anchor to be flush with the finished deck surface. Ground the anchor according to your local code requirements. This may require additional drilling and/or other tools. Copyright © 2019 Aqua Creek Products All Rights Reserved Revised 11/1/19...
- Page 4 [30.5 cm] 12" MIN [51 cm] 20" MAX ANCHOR SOCKET [15 cm] TOP OF SLAB 6" MIN [20.3cm] 8" MIN. 42" CEMENT/EPOXY 48" GROUNDING LUG FIGURE 1 Copyright © 2019 Aqua Creek Products All Rights Reserved Revised 11/1/19...
-
Page 5: Anchor Installation: New Construction
Verify all the measurements for accuracy and pour the deck as you normally would, making sure not to get any concrete inside the anchor system. Allow the concrete to cure before installing and using the lift. Copyright © 2019 Aqua Creek Products All Rights Reserved Revised 11/1/19... - Page 6 For any person operating the lift, please continue to operating instructions. Read carefully for comprehension. Copyright © 2019 Aqua Creek Products All Rights Reserved Revised 11/1/19...
- Page 7 Thank you for purchasing the Aqua Creek EZ 2 Pool Lift. Enjoy the pool and this product for many years with proper use and maintenance. See page 10 of this manual for proper care instructions. Copyright © 2019 Aqua Creek Products All Rights Reserved Revised 11/1/19...
-
Page 8: Proper Care Of Pool & Spa Lifts
To remove stubborn stains from finish, spray affected area with mild dish soap, rub briskly with a 3M Scotch Brite™ pad. Use white epoxy paint to touch up the finish. Apply wax to protect when dry. Copyright © 2019 Aqua Creek Products All Rights Reserved Revised 11/1/19... - Page 9 2X2 SQUARE BLACK CAP WF 1/4 WASHER, FLAT, 1/4, 316 SS WL 1/4 LOCK WASHER, 1/4, 316 SS BB 1/4 X 1/2 BOLT, 316 SS, 1/4-20 X 1/2 BHSCS Copyright © 2019 Aqua Creek Products All Rights Reserved Revised 11/1/19...
-
Page 10: Read Carefully
It is critical that all parts be carefully inspected prior to installation. If any damage occurred in transit, Aqua Creek Products, LLC must be notifi ed within three days of receipt of unit. Proper installation cannot be overstressed, as an improper installation voids Aqua Creek’s warranty and may affect the safety of the user. - Page 11 Hard Seat Installation To install the hard seat option onto an EZ Series lift the sling seat must fi rst be removed. To do this, simply unhook the hanger bar from the lift and store the hanger bar, chains and sling seat together.
