Textron EZGO RXV Shuttle 2+2 Service & Parts Manual page 34

BRAKES
THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO.
32 626156
33 *
34 610471
35 610635
36 *
37 613231
38 *
39 626146
40 606265
Page D-3
1 2 3 4 5
Park Brake Pad .........................................................................................
Solid Pin, 4mm x 57mm ............................................................................
Brake Pedal Cover ....................................................................................
Park Brake Pedal Cover............................................................................
Latch Ratchet ............................................................................................
Flanged Hex Head Bolt, M6 - 1 x 20mm Lg, Grade 8.8 ............................
Pivot Shaft.................................................................................................
Brake Cable Arm .......................................................................................
Flanged Hex Head Bolt, M6 - 1 x 12mm Lg, Grade 8.8 ............................
689390 Service Parts Manual
DESCRIPTION QTY.
1
1
1
1
2
2
1
1
1
