Textron EZGO RXV Shuttle 2+2 Service & Parts Manual page 108

SEATING
THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO.
20 00205G4
21
22
23 642444G02
24 638346G02
25 609851
26 16816G2
27 19853G1
28 614973
29 608290
30
31 603799
32
33 604473
34 601414
35 600525
36
37 615138
38 620878
39 75250G01
40 75250G02
41 600922
42
43 617576
44 19853G1
45 00762G8
46 17255G1
47 00891G3
48
49 612620
50 18436G1
Page R-9
1 2 3 4 5
Flat Head Screw, 1/4" - 20 x 1 1/2" Lg ......................................................
Floorboard Assembly (Flip Seat) (Includes Items 24 - 29) ..............................
Footrest Weldment (Fixed Seat) ...............................................................
Footrest Cover ..........................................................................................
Ratchet Rivet, .25" x .887" ........................................................................
Tube Cap, 1" x 1" ......................................................................................
Oval Reflector (Red) .................................................................................
Self Tapping Screw, #10 - 16 x 3/4" Lg .....................................................
Flanged Hex Head Bolt, M10 - 1.5 x 25mm Lg ...............................................
Seat Support ...................................................................................................
Flanged Hex Head Bolt, M10 -1.5 x 65mm Lg, Grade 8.8 ..............................
Lock Nut, M10 - 1.5 ........................................................................................
Deck Bed Assembly (Includes Items 38 - 41)..................................................
Middle Lifted Deck Bed .............................................................................
Seat Hinge (Passenger Side)....................................................................
Seat Hinge (Driver Side) ...........................................................................
Truss Head Screw With Patch Lock, 1/4" - 20 x 5/8" Lg ...........................
Rear Seat Frame (Lifted).................................................................................
Tube Cap, 1" x 1" ............................................................................................
Truss Head Phillips Screw, 5/16" - 18 x 2" Lg .................................................
Flat Washer (Teflon), .360" x .625" x .030" ......................................................
Lock Nut, 5/16" -18 ..........................................................................................
Rear Facing Seat Close Out............................................................................
Rivet, 1/4" x 3/4" .............................................................................................
689390 Service Parts Manual
DESCRIPTION QTY.
6
1
1
1
10
2
4
2
4
1
4
4
1
1
1
1
2
1
2
2
4
2
1
4
