Textron EZGO RXV Shuttle 2+2 Service & Parts Manual page 104

SEATING
THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO.
21 19853G1
22 638346G01
23 640653
24
25
26 603799
27 602415
28 600525
29
30 603800
31 603818
32
33 604723
34 604725
35
36 600530
37 600525
38 17618G1
39 600527
Page R-5
1 2 3 4 5
Tube Cap, 1" x 1" ......................................................................................
Footrest Weldment....................................................................................
Grip Tape...................................................................................................
Flanged Hex Head Bolt, M10 - 1.5 x 25mm Lg, Grade 8.8 .............................
Flanged Hex Head Bolt, M10 - 1.5 x 80mm Lg ...............................................
Lock Nut, M10 - 1.5 ........................................................................................
Flanged Hex Head Bolt, M10 - 1.5 x 50mm Lg, Grade 8.8 .............................
Barrel Clip, M10 - 1.5.......................................................................................
Arm Rest (Driver Side) ....................................................................................
Arm Rest (Passenger Side).............................................................................
Button Head Torx Bolt, M10 - 1.5 x 25mm Lg, Grade 8.8................................
Lock Nut, M10 - 1.5 ........................................................................................
Nylon Clamp, 8" Lg (Not Illustrated) ................................................................
Button Head Torx Bolt, M10 - 1.5 x 60mm Lg, Grade 8.8................................
689390 Service Parts Manual
DESCRIPTION QTY.
2
1
1
4
2
2
2
2
1
1
2
2
2
4
