Front Suspension And Steering - Textron EZGO RXV Shuttle 2+2 Service & Parts Manual

FRONT SUSPENSION AND STEERING

THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO.
32 608089
33 608090
34 608086
35
36 601340
37 602085
38
39 602415
40 600525
41
42 601754
43 600525
44
45 618329
46 602020
47
48 608005
49 10387G2
Page L-3
1 2 3 4 5
Control Arm Assembly (Includes Items 33 - 34) ..............................................
Control Arm ...............................................................................................
Mounting Sleeve (Rubber) ........................................................................
Control Arm Bushing........................................................................................
Control Arm Carrier Tube.................................................................................
Flanged Hex Head Bolt, M10 - 1.5 x 80mm Lg ...............................................
Lock Nut, M10 - 1.5 ........................................................................................
Flanged Hex Head Bolt, M10 - 1.5 x 100mm Lg .............................................
Lock Nut, M10 - 1.5 ........................................................................................
Steering Rack Assembly..................................................................................
Socket Head Bolt, M10 - 1.5 x 50mm Lg, Grade 8.8.......................................
Castle Nut (SS), M12 - 1.25 ............................................................................
Cotter Pin, .094" x 1" .......................................................................................
689390 Service Parts Manual
DESCRIPTION QTY.
1
1
2
2
2
2
2
1
1
1
3
2
2
