6,500 WATT GENERATOR
GÉNÉRATRICE DE 6 500 WATTS
GENERADOR 6 500 WATTS
RY906500
NOTICE
Do not use E15 or E85 fuel in this
product. It is a violation of federal law
and will damage the unit and void your
warranty. Only use unleaded gasoline
containing up to 10% ethanol.
Ne pas utiliser d'essence E15 ou E85 dans ce produit. Une
telle utilisation représente une violation de la loi fédérale
et endommagera l'appareil et annulera la garantie. Utiliser
seulement de l'essence sans plomb ne contenant pas plus
de 10 % d'éthanol.
No utilice combustibles E15 o E85 con este producto. Esto
constituye una violación a la ley federal, dañará la unidad y
anulará la garantía. Utilice únicamente gasolina sin plomo
que contiene hasta 10% de etanol.

TABLE OF CONTENTS

 Specific Safety Rules ........................... 4
 Symbols ............................................5-7
 Electrical ...........................................8-9
 Features .............................................10
 Assembly ......................................11-12
 Operation ......................................12-14
 Maintenance .................................15-17
 Troubleshooting ................................. 18
 Warranty .............................................19
 Parts Ordering / Service ....... Back Page
WARNING:
To reduce the risk of
injury, the user must read and understand
the operator's manual before using this
product.
SAVE THIS MANUAL FOR
FUTURE REFERENCE
AVIS
AVISO
TABLE DES MATIÈRES
concernant la sécurité ......................3-4
 Symboles ..........................................5-7
 Caractéristiques ................................. 10
 Assemblage ..................................11-12
 Utilisation ......................................12-15
 Entretien ........................................15-18
 Dépannage .........................................19
 Garantie .............................................20
 Commande de pièces /
réparation ............................Páge arrière
AVERTISSEMENT :
réduire les risques de blessures,
l'utilisateur doit lire et veiller à bien
comprendre le manuel d'utilisation avant
d'employer ce produit.
CONSERVER CE MANUEL
POUR FUTURE RÉFÉRENCE
OPERATOR'S MANUAL
MANUEL D'UTILISATION
MANUAL DEL OPERADOR
NEUTRAL BONDED TO FRAME
CONNECTEUR NEUTRE RELIÉ AU CADRE
PUNTO NEUTRO CONECTADO AL MARCO
 Símbolos ...........................................5-7
 Aspectos eléctricos ..........................8-9
 Características ................................... 10
 Armado .........................................11-12
 Funcionamiento ............................12-15
 Mantenimiento ..............................15-18
 Corrección de problemas .................. 19
 Garantía .............................................20
 Pedidos de piezas/
Pour
riesgo de lesiones, el usuario debe leer
y comprender el manual del operador
antes de usar este producto.
PARA FUTURAS CONSULTAS
ÍNDICE DE CONTENIDO
importantes .......................................3-4
servicio ............................ Pág. posterior
Para reducir el
GUARDE ESTE MANUAL
