Summary of Contents for Candy RTT 2131WSZ-19
- Page 1 RTT 2131WSZ-19 RTT 2151WSZ-19 0030516072...
-
Page 2: Table Of Contents
Contents Safety precautions ................Packing list ....................Machine components ..................Installation and adjustment ..............Pre-wash preparation ..............Washing sequence ................Disposal after washing ................. Troubleshooting ................... Speci cations Back cover ................ -
Page 3: Safety Precautions
Safety precautions Meaning and description of the symbols Contents marked with this symbol relate to product and WARNING user safety. Please operate the machine in strict conformity to the contents of this manual to minimize the risk of personal injury and/or damage to the machine. - Page 4 Do not stretch hands into the workingmachine. It is Do not share the outlet with other electric dangerous even if the rotation is slow. Take special appliances. If the power plug is damaged, care o f the children.This appliance is not intended or feels loose when plugged into the for use by persons (including children) with educe physical , sensor y or mental capabilities...
-
Page 5: Packing List
Packing list Twin-tub washing Water intake Gland Draining Bottom machine hose hose Machine Components Wash time Drain Spin time Wash program If you wish to set it Intensity can be Warning: do not If to set to less than for less than 2 set to mormal set the switch on 1 min, in order to... -
Page 6: Installation And Adjustment
Installation and adjustment For your security and to ensure correct operation of the machine, please install and adjust the machine according to this manual’s instructions. Installation of the lint filter Place the bottom side of the lint filter into the overflow filter, then push the top side into the overflow filter overflow filter. - Page 7 1). 2.Carefully tilt the washing machine to front and install the bottom legs at the back of the base.Make sure that legs are installed in place.(Figure 2) On model RTT 2131WSZ-19. Bottom legs Bottom legs...
-
Page 8: Pre-Wash Preparation
Pre-wash Preparation Basic know-how The maximum capacity during washing and spinning cycles refers to the max weight of standard dry laundry that can be washed or spun at one time. The laundry quantity during one washing cycle should be lower than the rated capacity. Thickness, size, and the type of cloth will influence actual washing capacity. - Page 9 Dissolve powder whitening agents before use. Note: The energy test program(RTT 2131WSZ-19) Full load Cotton 60:Manually fill in hot water(35 to 36 liters)and cold water up to the 4 water level after Normal wash 45min,then keep washing 30min Drain Spin twice each for 5min 5min...
-
Page 10: Washing Sequence
Washing sequence Washing 1.Inlet selector Set the selector to “WASH”.(Figure1) Figure 1 2.Add water Machine begins to dispense detergent uniformly.(Figure2) Figure 2 3.Put in the wash load. Add more water as necessary.(Figure3) Figure 3 4 Select intensity. normal Select “SOFT ” or “NORMAL” water flow soft intensity according to the wash load.(Figure4) Figure 4... - Page 11 Mid-wash spin cycle 1. Put the laundries into the spin tub evenly and smoothly. 2.Spin:(1) Distribute the laundry into the spin tub smoothly and evenly. Note: the gland must be inserted properly even if the laundry quantity is small. Gland Push Push Proper...
- Page 12 The rinse cycle Rinse with water-filling 1.Place laundry into the washing machine. Place laundry into the washing machine. Select the appropriate current according to the laundries. 2.Add water. Add the appropriate amount of water. 3.Rinse Adjust the wash timer to 5-7 minutes for the rinse cycle Rinsing with stored water (Repeat the mid-wash spin cycle and rinse cycle with stored water 2-3 times) 1.Place laundry into the washing machine.
-
Page 13: Disposal After Washing
Disposal after washing After each use, be sure to clean the lint and foreign materials from the lint filter and the overflow filter in a timely fashion. Removing lint is important for healthy operation of the machine. Please remove the plug from the power outlet first before cleaning. Cleaning the lint lter The lint filter should always be used during washing and should be cleaned after each use in a timely fashion. - Page 14 Cleaning the over ow lter Too much lint in the overflow filter will influence normal usage of the machine. Remember to clean it once every two months. Elastic fixing claw 1.Take off the over ow lter. Nip the elastic fixing claw and pull in the direction of the arrow to remove (as demonstrated in the figure to the right).
- Page 15 Troubleshooting When the remaining water is frozen Prevent the freezing Pour hot water below (be sure to drain the water Below 50 50°C into the wash cycle completely after each use) 2~3L compartment to soak it After completely draining, set completely, then using the “DRAIN SELECTOR”...
-
Page 16: Speci Cations
Speci cations Model RTT 2131WSZ-19 RTT 2151WSZ-19 Rated Voltage 230V~ 230V~ Rated Frequency 60Hz 60Hz Washing Capacity 13kg 15kg Spin-dry Capacity 10kg 14kg Rated Wash Power 420W 450W Rated Spin Power 280W 310W Total Input Power 700W 760W Rated Current of Fuse... - Page 17 IPX4 IPX4 www.candy.ae...
- Page 18 " " ) " " ) " "...
- Page 21 " " ) " "...
- Page 22 (1) : ) " "...
- Page 23 ) " " ) " ) " " " " " ) .(...
- Page 24 :(RTT 2131WSZ-19) :(RTT 2151WSZ-19)
- Page 25 " "...
- Page 26 . .2 .RTT 2131WSZ-19...
- Page 27 ." " " "...
- Page 31 2................4..................4.................. 5................7..............9................... 12............................................
- Page 32 RTT 2131WSZ-19 RTT 2151WSZ-19...
