- Page 1 English High tip bucket 2019 1 Operator's Manual for Attachment High tip bucket Product number 1050 mm A2631 1280 mm A2824 www.avanttecno.com A423414 2019 1 EN 2017-...
- Page 2 High tip bucket 2019 1...
-
Page 3: Table Of Contents
High tip bucket 2019 1 CONTENTS 1. FOREWORD ............................4 Warning symbols used in this manual ........................... 5 2. DESIGNED PURPOSE OF USE ......................6 3. SAFETY INSTRUCTIONS FOR USING THE ATTACHMENT ............7 Safe shutdown procedure ............................9 Personal protective equipment ..........................10 4. -
Page 4: Foreword
If you sell or transfer the equipment, be sure to hand over this manual to the new owner. If the manual is lost or damaged, you can request a new one from your Avant dealer or from the manufacturer. -
Page 5: Warning Symbols Used In This Manual
5 (26) Warning symbols used in this manual The following warning symbols are used throughout this manual. They indicate factors that must be taken into account to reduce the risk of personal injury or damage to property: WARNING SAFETY ALERT SYMBOL This symbol means: “Warning, be alert! Your safety is involved!”... -
Page 6: Designed Purpose Of Use
6 (26) 2. Designed purpose of use The AVANT High tip buckets are attachments that are designed and manufactured to be used with AVANT multi purpose loaders that are shown in Table 1. They are versatile buckets for earth-moving tasks, material handling, levelling, and snow clearing work. -
Page 7: Safety Instructions For Using The Attachment
7 (26) 3. Safety instructions for using the attachment Please bear in mind that safety is the result of several factors. The loader-attachment combination is highly powerful and improper or careless use or maintenance may cause serious personal injury or property damage. - Page 8 Observe the local regulations concerning the use of the equipment on public roads. The loader may need to be registered for road use. Contact your local Avant dealer or local authorities for more information. Risk of crushing - Never allow anyone to get under a lifted attachment or loader boom.
-
Page 9: Safe Shutdown Procedure
9 (26) Pinching hazard - Keep hands and feet away from moving parts. Set the bucket to a safe position (closed), before leaving the driver's seat as described in this manual. WARNING Operate the attachment only from the driver’s seat. Never climb on the bucket. -
Page 10: Personal Protective Equipment
10 (26) 3.2 Personal protective equipment Remember to wear proper personal protective equipment: The noise level at the driver's seat may exceed 85 dB(A) depending on loader model and operating cycle. Extended exposure to loud noise can cause hearing impairment. Wear hearing protection while working with the loader. ... -
Page 11: Technical Specifications
350 l 30 l/min Recommended input of hydraulic energy: 20,0 MPa (200 bar) Compatible AVANT loader models: See Table 1 on page *Volume is maximum, heaped capacity 4.1 Safety labels and main components of the attachment Listed below are the labels and markings on the attachment. They must be visible and readable on the equipment. - Page 12 12 (26) Attachment identification plate A46771 A46772 A46803 To apply a new label: Clean the surface thoroughly to remove all grease. Allow it to dry completely. Peel off the protective film of the label and press firmly to apply. Take care not to touch the glue of the label. Table 3 - Decal locations and warning messages Decal Warning message...
-
Page 13: Attaching The Attachment
Do not stay in the area between the attachment and the loader. Mount the attachment only on level surface. WARNING Never move or lift an attachment that has not been locked. Avant quick coupling system: Step 1: Lift the quick attach plate locking pins up and turn them backwards into the slot so that they are locked in the upper position. -
Page 14: Connecting And Disconnecting Hydraulic Hoses
5.1 Connecting and disconnecting hydraulic hoses On Avant loaders the hydraulic hoses are connected using the multi connector system. If you have an Avant 300-700 series loader with the conventional quick couplers and wish to change to the multi connector system, contact your Avant dealer or service point for instructions or installation services. - Page 15 15 (26) Keep all fittings as clean as possible; use the protective caps on both the attachment and the loader. Dirt, ice, etc. may make using the fittings significantly more difficult. Never leave the hoses hanging on the ground; place the couplings onto the holder on the attachment.
-
Page 16: Instructions For Use
16 (26) 6. Instructions for use Practise the use of the attachment and the controls of the loader in a safe area. If you are unfamiliar with the particular loader model, it is recommended to practice its use without any attachments. Risk of tipping over - Avoid overload. -
Page 17: Checks Before Use
17 (26) 6.1 Checks before use Ensure that bystanders are at a safe distance when operating the equipment. Do not let anyone to enter danger area of the boom or to stay directly in front of the loader. Also make sure that it is safe to reverse with the loader. - Page 18 18 (26) Once the bucket is almost full, lift the bucket with loader boom. Keep driving slowly forward. To operate the high tip bucket: Move auxiliary hydraulics control lever towards locking position electric buttons of the optional electric joystick) to empty the bucket.
-
Page 19: Material Handling
19 (26) If the loader is not equipped with the boom self levelling: Prevent material from falling on you - Monitor the position of the bucket. When lifting material to a high level, the bucket plate must be simultaneously tilted to prevent the load from falling from on the loader or the operator. -
Page 20: Working On Uneven Ground
Read the instructions provided with the tilt adapter or in the operator's manual of the loader. More information about the tilt adapters is available from your AVANT retailer or from the AVANT web pages at www.avanttecno.com. Adapter plates reduce lifting capacity - Do not use adapters with heavy loads or attachments. - Page 21 21 (26) Climbing on the bucket is prohibited. Clean the attachment before long storage periods, touch up the paint where needed, grease the lubrication points and oil the visible parts of the hydraulic cylinder shaft to prevent rust damage.
-
Page 22: Maintenance And Service
Finding any fault means that the hydraulic hose or component must be replaced and the equipment must not be used until it is repaired. Spare parts are available from your nearest AVANT retailer or authorised service point. Leave the repair work to professional service technicians, if you don’t have adequate knowledge and... -
Page 23: Cleaning The Attachment
23 (26) 7.2 Cleaning the attachment Clean the attachment regularly to prevent accumulation of dirt which is more difficult to remove. A pressure washer and mild detergent can be used for cleaning. Do not use strong solvents, and do not spray directly at the hydraulic components, or at the labels on the attachment. -
Page 24: Warranty Terms
24 (26) 8. Warranty terms Avant Tecno Oy grants a warranty of one year (12 months) from the date of purchase for the attachment it manufactures. The warranty covers repair costs as follows: Work costs are covered, if the repair is not performed at the factory. - Page 25 SFS-EN ISO 12100, SFS-EN ISO 4413 Mallit / Modeller / Models Avant Hydraulitoiminen kauha; Avant-kuormaajan työlaite A2631 1050 mm Hydraulisk skopa; arbetsredskap för Avant lastare Hydraulic bucket; attachment for Avant loaders A2824 1280 mm 18.11.2019 Ylöjärvi, Finland Risto Käkelä, Toimitusjohtaja / Verkställande direktör /...
