- Page 1 Drum type concrete mixer 2013 1 Operator’s Operator’s manual for Attachment Operator’s Operator’s manual for Attachment manual for Attachment manual for Attachment Product number: 300-700-series loaders: A2950 Please read this manual carefully before using the equipment, and follow all instructions. Keep this manual for later reference.
- Page 2 Drum type concrete mixer 2013 1...
-
Page 3: Table Of Contents
Drum type concrete mixer 2013 1 CONTENTS 1. Foreword ..........................4 2. Designed purpose of use......................5 3. Safety instructions for the concrete mixer .................5 4. Concrete mixer specifications....................8 4.1. Safety labels ........................... 5. Assembly of the concrete mixer....................10 5.1. Coupling the attachment to the loader ..................... 5.2. -
Page 4: Foreword
4(20) 1. Foreword Avant Tecno Oy and Sami AS would like to thank you for your purchase of this attachment for your Avant loader. The attachment has been designed and manufactured on the basis of years of product development and experience. By familiarising yourself with this manual and following the instructions, you ascertain your safety and ensure the reliable operation and long service life of the equipment. -
Page 5: Designed Purpose Of Use
5(20) 2. Designed purpose of use This hydraulically operated drum type concrete mixer is an attachment intended to be used with AVANT 300- 700 series multi purpose loaders. The concrete mixer is an essential attachment for mixing and transporting concrete, mortar, plaster or similar material even at difficult locations. Pouring concrete to desired location is possible by simply tilting the drum with the loader boom. - Page 6 6(20) Read the safety instructions carefully before handling the attachment • When attaching the attachment to the loader, ensure that the locking pins of the loader's quick attach plate are in the lower position and that they have locked the attachment to the loader.
- Page 7 7(20) Beware of hazards of entanglement and crushing between moving components whenever using the concrete mixer. Always stop the attachment by turning the auxiliary hydraulics control lever to its neutral position and before reaching into the mixing drum, shut down the loader engine first and release the residual pressure of the hydraulic system.
-
Page 8: Concrete Mixer Specifications
Maximum rotating speed: (60 rpm, 30 l/min) 0,3 – 0,6 rev / s Recommended rotating (20 – 40 rpm, speed: 10 – 20 l/min) Suitable AVANT loader: 300 - 700 Graph 1 – Rotating speed (revolutions per second) and hydraulic oil flow... -
Page 9: Safety Labels
9(20) 4.1. Safety labels Listed below are the markings and labels fastened to the attachment. The labels must be visible on the equipment. Replace any missing or unclear labels with new ones. New labels are available from your retailer or from service contractors. The warning labels contain important safety information and they help to identify and remember hazards related to the equipment. -
Page 10: Assembly Of The Concrete Mixer
10(20) 5. Assembly of the concrete mixer The attachment is ready for use as delivered. Attach the attachment and its hydraulic hoses to the loader as instructed below. 5.1. Coupling the attachment to the loader Coupling the attachment to the loader is quick and easy, but it must be done carefully. The attachment is fixed to the loader boom by using the quick attach plate and the counterpart on the attachment. -
Page 11: Connecting And Disconnecting Hydraulic Couplings
5.2. Connecting and disconnecting hydraulic couplings The default connector for hydraulic couplings is the multiconnector system. If you want to change the type of the hydraulic couplings of the attachment or the loader, contact your Avant dealer or service point for instructions or installation services. -
Page 12: Cleaning, Uncoupling And Storage
12(20) Conventional quick couplings (alternative couplings for some loader models): Before connecting or disconnecting the standard quick couplings, the residual pressure must be released as shown above. If the pressure is not released, the fittings will not connect easily. To connect and disconnect the standard couplings, move the collar at the end of the female fitting. -
Page 13: Instructions For Use
13(20) 6. Instructions for use Check the attachment and the operating environment once more before starting to work. Quick inspection of the equipment and the operating area before use are parts of ensuring safety and the best performance of the equipment. Keep a safe distance to the mixer when it is in operation and stay back if other person operates the controls of the loader. -
Page 14: Slope Operation And Uneven Terrain
14(20) Start the mixer only when it is ready to be used. Do not leave the equipment running unattended. Do not go near the equipment when another person operates the controls of the loader. The concrete mixer is started by locking on the auxiliary hydraulics control lever of the loader. Correct rotating direction is clockwise when seen from front of the mixer. -
Page 15: Maintenance And Servicing
Leaking hydraulic fluid may penetrate skin and cause serious injuries. Seek medical attention immediately in case hydraulic fluid penetrates the skin. Hydraulic fluid is also harmful to the environment. Operate only with hydraulic oil that is accepted for use in Avant loaders. Never handle hydraulic components when... -
Page 16: Warranty Terms
16(20) 8. Warranty terms Avant Tecno Oy grants a warranty of one year (12 months) for the attachment from the date of purchase. The warranty covers repair costs as follows: • Work costs are covered, if the repair is not performed at the factory. -
Page 17: Spare Parts List
Drum type concrete mixer 2013 1 9. Spare parts list... - Page 18 Drum type concrete mixer 2013 1...
