This 'Original instructions' document assumes that the operator carrying out any operation with this
product is trained and competent to do so. This manual does not attempt to cover all details or variations
in the equipment. Nor does this manual claim to provide for every possible contingency met in connection
with the installation, operation, or maintenance thereof. Should further information be desired, or should
a particular problem arise which is not covered in sufficient detail, the matter should be referred to
Hi-Force.
OPERATING INSTRUCTION MANUAL
TPE-A SERIES | ELECTRIC DRIVEN TORQUE WRENCH
Hi-Force TPE series Electric Driven Torque Wrench Pumps are premium pumps designed for use with
Hi-Force Hydraulic Torque Wrenches. TPE Pumps can be used to power up to 4 torque wrenches
simultaneously (all operating at the same pressure). Output pressure is fully adjustable and can be set to
any value up to a maximum working pressure of 700 bar (10,000 psi). This manual applies to the Hi-Force
TPE series Analogue, Electric Driven Torque Wrench Pumps Only. It contains the latest product information
available at the time of publication and approval. For information relating to the servicing of an Electric
Driven Torque Wrench Pump, see the servicing instructions, which are available on the Hi-Force website.
Hi-Force reserves the right to make changes to this document at any time without notice.
Operating Instruction Manual:
PUMPS - PREMIUM LINE (ANALOGUE)
1
OM-TPE-A-01
Serial Numbers:
All
Advertisement
Table of Contents
Related Manuals for Hi-Force TPE-A Series
Summary of Contents for Hi-Force TPE-A Series
- Page 1 (all operating at the same pressure). Output pressure is fully adjustable and can be set to any value up to a maximum working pressure of 700 bar (10,000 psi). This manual applies to the Hi-Force TPE series Analogue, Electric Driven Torque Wrench Pumps Only. It contains the latest product information available at the time of publication and approval.
-
Page 2: Table Of Contents
Operating Instruction Manual: Serial Numbers: OM-TPE-A-01 Table of Contents 1.0 Inspection upon Receipt ..............3 2.0 Safety Precautions ................3 3.0 Declaration of Incorporation / Conformity ........6 4.0 Component Identification ..............7 5.0 Installation / Setup ................10 6.0 Operation ..................17 7.0 Maintenance and Storage .............. -
Page 3: Inspection Upon Receipt
If in doubt on the correct use of any Hi-Force equipment, contact your nearest Hi-Force office or distributor. Only qualified personnel should be allowed to operate hydraulic equipment. If an operator has not been trained on high-pressure hydraulic equipment and its safe usage, consult your local Hi-Force sales office or distributor who can offer training courses for operators. - Page 4 Operating Instruction Manual: Serial Numbers: OM-TPE-A-01 2.4 General Hydraulic System Safety Precautions Failure to observe and obey the following safety precautions could result in property damage, significant personal injury or death; When operating any hydraulic equipment, all operators should ensure that all necessary personal protective equipment (PPE) is worn, as specified by their employer.
- Page 5 NEVER exceed the maximum rated pressure of any hydraulic equipment. Hi-Force manufactures its TPE hydraulic pumps to operate at a maximum working pressure of 700 bar (10,000 psi). DO NOT connect hydraulic torque equipment with a lower pressure capacity rating to any Hi-Force pump of this model series.
-
Page 6: Declaration Of Incorporation / Conformity
3.0 Declaration of Incorporation / Conformity Hi-Force declares that this product has been tested and complies with the standards set out in the relevant EU directives. The EU Declaration of Incorporation / Conformity is included as Annex A to this instruction... -
Page 7: Component Identification
Operating Instruction Manual: Serial Numbers: OM-TPE-A-01 4.0 Component Identification Oil Reservoir Oil Pressure Gauge Electric Motor Tool Advance Coupler (700 bar maximum) Oil Cooling Heat Exchanger Tool Retract Coupler (90 bar maximum) ‘Solenoid Valve’ Manual Override Button Oil Temperature/Level Gauge Figure 4.1: Component Identification... - Page 8 Operating Instruction Manual: Serial Numbers: OM-TPE-A-01 Electrical Control Box Multi-Outlet 4-Way Split-Block Emergency Stop Button Roll Frame Adjustable Pressure Relief Valve with Oil Filler / Breather Cap Locking Wing Nut See Section 5.4 Figure 4.2: Component Identification...
- Page 9 Operating Instruction Manual: Serial Numbers: OM-TPE-A-01 “Heat Exchanger” Fan “Advance” Button “Auto-Cycle” Button Flying Lead “Stop / Emergency Stop” Button Oil Drain Plug Control Pendant Figure 4.3: Component Identification...
-
Page 10: Installation / Setup
Operating Instruction Manual: Serial Numbers: OM-TPE-A-01 5.0 Installation / Setup 5.1 Before First Use / Preparation 1. Immediately after unpacking, examine the unit for signs of transit damage and if found contact the shipping company. 2. Establish the oil level in the oil reservoir (1) using the oil level gauge (8). Depending on the shipping method used, the reservoir may either be supplied full or empty. - Page 11 Make sure both coupler halves are clean before connecting. If you are NOT using a Hi-Force Torque Wrench with the pump, or if the wrench or hoses have been modified, make sure that the wrench is connected correctly so that the male high-pressure advance coupler (6) is connected to the advance port on the tool.
- Page 12 Operating Instruction Manual: Serial Numbers: OM-TPE-A-01 5.3.3. Connecting a Torque Wrench to the Pump Connect the female coupler on the red hose to the male advance coupler (6) on the pump. Connect the male coupler on the black hose to the female retract coupler (7) on the pump. Figure 5.3: Connecting to the Pump ...
- Page 13 OM-TPE-A-01 5.4 Connection of Additional Torque Wrenches Hi-Force TPE-A Pumps are equipped with additional ports allowing for up to 4 Torque wrenches to be driven simultaneously (all operating at the same pressure). This feature can be useful for even tightening of large joints. However, it must be noted that multiple torque wrenches will operate slower than a single torque wrench would, so this is not necessarily a time-saving method.
- Page 14 5.7 Bleeding Trapped Air from the System Torque wrenches and hoses are not always completely filled with oil when new. Hi-Force HTWH hoses are supplied pre-filled with oil, but NEVER assume that there are no air pockets in a hose. Air trapped in the system will lead to erratic operation of the torque tool.
- Page 15 DO NOT TOUCH. NOTE: When longer hoses are used (greater than 5m), the above procedure may not remove all the air from the system. In these cases, contact your Hi-Force representative for advice on pre-filling hoses with hydraulic oil. ...
- Page 16 Operating Instruction Manual: Serial Numbers: OM-TPE-A-01 5.8 System Leak Test & Function Test NOTE: These tests are performed as part of the process detailed in section 5.7 and need not be repeated if the full process described in section 5.7 has been performed. Low-Pressure Leak Test &...
-
Page 17: Operation
OM-TPE-A-01 6.0 Operation Hi-Force TPE-A Torque Wrench Pumps are used to power double-acting Hydraulic Torque Wrenches. Make sure you read this manual in conjunction with the Torque Wrench’s operating instruction manual to ensure correct and safe operation of all hydraulic equipment in the system. - Page 18 Operating Instruction Manual: Serial Numbers: OM-TPE-A-01 6.2. Setting the Pressure (Torque) Before setting the pump pressure it is necessary to determine what pump pressure will result in the torque value required. Use the tool-specific pressure-torque conversion chart provided with the torque wrench to determine the pump pressure that corresponds to the required torque value.
- Page 19 Operating Instruction Manual: Serial Numbers: OM-TPE-A-01 6.3 Pendant Control Buttons (figure 6.2) ON / ADVANCE The On / Advance button (19) is a dual function button. A single press of the button will start the motor and set the pump to retract mode. Once started, pressing and holding the button again will set the pump to advance mode i.e.
- Page 20 All operating functions of the pump are performed via the 3 buttons on the control pendant (18). (See figure 6.2) Hi-force recommends that operation of the pump/wrench combination be a minimum 2 person job, one to operate the pump and one to operate the wrench. An additional operator will be required for each addition wrench connected to the pump.
-
Page 21: Maintenance And Storage
Routinely perform a visual inspection of the pump and electric cables for signs of damage. Any electrical cables showing signs of damage MUST be replaced by a Hi-Force authorised repair centre, or by a competent electrician. ... -
Page 22: Specifications
Operating Instruction Manual: Serial Numbers: OM-TPE-A-01 8.0 Specifications Refer to the nameplate on the pump for model identification. TPE-A | Torque Wrench Pumps – Electric Driven (Analogue) Max Oil Weight Gauge Model Pressure Capacity Temp. (incl. oil) Power Supply Number Gauge Reading (litres) -
Page 23: System Components / Accessories
Operating Instruction Manual: Serial Numbers: OM-TPE-A-01 9.0 System Components / Accessories (Refer to the Hi-Force website or latest Hi-Force catalogue, for further details) HTWH Series High-Pressure Hydraulic Hoses (Up to 100m). HTWR1 Torque Wrench Hose Reel High-Pressure Quick-Release Male and Female Half Couplers. -
Page 24: Pressure Conversion Table
Operating Instruction Manual: Serial Numbers: OM-TPE-A-01 10.0 Pressure Conversion Table kgf / cm kgf / cm 10.2 5221 367.1 20.4 5366 377.3 30.6 5511 387.5 40.8 5656 397.7 51.0 5802 407.9 61.2 5947 418.1 1015 71.4 6092 428.3 1160 81.6 6237 438.5 1305... -
Page 25: Troubleshooting
Operating Instruction Manual: Serial Numbers: OM-TPE-A-01 11.0 Troubleshooting Hi-Force TPE-A Torque Wrench Pumps should be serviced and repaired only by authorised Hi-Force repair centres. The following table gives possible causes and solutions for common problems. TROUBLESHOOTING GUIDE Problem Possible Cause Solution 1. - Page 26 Make sure the tool is correctly rated for the capacity. application. 10. Erratic tool a. Leakage from pump or valve Contact your local Hi-Force office / distributor. movement. internal components. b. Internal leak, due to damaged/worn Contact your local Hi-Force office / distributor.
-
Page 27: Contact Details
Operating Instruction Manual: Serial Numbers: OM-TPE-A-01 UK Head Office: Hi-Force Limited Prospect Way, Daventry, Northamptonshire NN11 8PL United Kingdom Tel: + 44 1327 301000 Fax: + 44 1327 706555 Email: daventry@hi-force.com... - Page 28 Baku Milano Azerbaijan Italy Tel: +994 124 474 100 Tel: +39 0257 607 174 Email: baku@hi-force.com Email: italy@hi-force.com Hi-Force Hydraulics (Asia) S.B. Hi-Force Nederland B.V. Selangor Numansdorp Malaysia Netherlands Tel: +603 5525 4203 Tel: +31 85 902 8111 Email: malaysia@hi-force.com Email: holland@hi-force.com...
