This 'Original instructions' document assumes that the operator carrying out any operation with this
product is trained and competent to do so. This manual does not attempt to cover all details or variations
in the equipment. Nor does this manual claim to provide for every possible contingency met in connection
with the installation, operation, or maintenance thereof. Should further information be desired, or should
a particular problem arise which is not covered in sufficient detail, the matter should be referred to
Hi-Force.
OPERATING INSTRUCTION MANUAL
HTWP SERIES | ELECTRIC DRIVEN TORQUE WRENCH
This manual applies to the Hi-Force HTWP Electric range of torque pumps. It contains the latest
product information available at the time of publication and approval. Information pertaining to the
servicing of the torque pump is contained in the servicing instructions which are available on the
Hi-Force website. The right is reserved to make changes at any time without notice.
Operating Instruction Manual:
OM-HTWP-ELECTRIC-01
PUMPS
1
Serial Numbers:
From: BP5141
Advertisement
Table of Contents
Related Manuals for Hi-Force HTWP Series
Summary of Contents for Hi-Force HTWP Series
- Page 1 HTWP SERIES | ELECTRIC DRIVEN TORQUE WRENCH PUMPS This manual applies to the Hi-Force HTWP Electric range of torque pumps. It contains the latest product information available at the time of publication and approval. Information pertaining to the servicing of the torque pump is contained in the servicing instructions which are available on the...
-
Page 2: Table Of Contents
Operating Instruction Manual: Serial Numbers: OM-HTWP-ELECTRIC-01 From: BP5141 Table of Contents 1.0 Inspection upon Receipt ..............3 2.0 Safety Precautions ................3 3.0 Declaration of Incorporation / Conformity ........6 4.0 Specifications ................... 7 4.0 Component Identification ..............8 5.0 Installation / Setup ................10 6.0 Operation .................. -
Page 3: Inspection Upon Receipt
If in doubt on the correct use of any Hi-Force equipment, contact your nearest Hi-Force office or distributor. Only qualified personnel should be allowed to operate hydraulic equipment. If an operator has not been trained on high-pressure hydraulic equipment and its safe usage, consult your local Hi-Force sales office or distributor who can offer training courses for operators. - Page 4 Operating Instruction Manual: Serial Numbers: OM-HTWP-ELECTRIC-01 From: BP5141 2.4 General Hydraulic System Safety Precautions Failure to observe and obey the following safety precautions could result in property damage, significant personal injury or death; When operating any hydraulic equipment, all operators should ensure that all necessary personal protective equipment (PPE) is worn, as specified by their employer.
- Page 5 NEVER exceed the maximum rated pressure of any hydraulic equipment. Hi-Force manufactures its HTWP Electric hydraulic pumps to operate at a maximum working pressure of 700 bar (10,000 psi). DO NOT connect hydraulic torque equipment with a lower pressure capacity rating to any Hi-Force pump of this model series.
-
Page 6: Declaration Of Incorporation / Conformity
To protect your warranty, only use the hydraulic oil grade specified in Section 5.2. 3.0 Declaration of Incorporation / Conformity Hi-Force declares that this product has been tested and complies with the standards and declarations as set out in the Declaration of Incorporation/Conformity (DoI/DoC). The DoI/DoC is included as Annex A to this instruction document and is supplied with all shipments of this product. -
Page 7: Specifications
Oil Specification Hi-Force tools use 2 grades of oil, dependant on the tool. The tools are designed to operate at temperatures of -20 to 80 degrees C. Details of the oil used in this product can be found in Section 5.2. -
Page 8: Component Identification
Operating Instruction Manual: Serial Numbers: OM-HTWP-ELECTRIC-01 From: BP5141 4.0 Component Identification Start / Stop relay switch Oil level / Temperature gauge Electric Motor Drain plug Adjustable pressure relief valve Tool Advance Coupler (700 bar maximum) Oil reservoir Tool Retract Coupler (120 bar maximum) Figure 4.1: Component Identification... - Page 9 Operating Instruction Manual: Serial Numbers: OM-HTWP-ELECTRIC-01 From: BP5141 Oil pressure gauge. Tool Advance button Oil filler / breather cap. Motor control box Roll frame Pendant control Figure 4.2: Component Identification...
-
Page 10: Installation / Setup
Operating Instruction Manual: Serial Numbers: OM-HTWP-ELECTRIC-01 From: BP5141 5.0 Installation / Setup 5.1 Before First Use / Preparation 1. Immediately after unpacking, examine the unit for signs of transit damage and if found contact the shipping company. 2. Establish the oil level in the oil reservoir (4) using the oil level gauge (5). Depending on the shipping method used, the reservoir may either be supplied full or empty. - Page 11 Make sure both coupler halves are clean before connecting. If you are NOT using a Hi-Force Torque Wrench with the pump, or if the wrench or hoses have been modified, make sure that the wrench is connected correctly so that the male high-pressure advance coupler (7) is connected to the advance port on the tool.
- Page 12 Operating Instruction Manual: Serial Numbers: OM-HTWP-ELECTRIC-01 From: BP5141 5.3.3. Connecting a Torque Wrench to the Pump Connect the female coupler on the red hose to the male advance coupler (7) on the pump. Connect the male coupler on the black hose to the female retract coupler (8) on the pump. Figure 5.3: Connecting to the Pump ...
- Page 13 5.7 Bleeding Trapped Air from the System Torque wrenches and hoses are not always completely filled with oil when new. Hi-Force HTWH hoses are supplied pre-filled with oil, but NEVER assume that there are no air pockets in a hose. Air trapped in the system will lead to erratic operation of the torque tool.
- Page 14 DO NOT TOUCH. NOTE: When longer hoses are used (greater than 5m), the above procedure may not remove all the air from the system. In these cases, contact your Hi-Force representative for advice on pre-filling hoses with hydraulic oil. ...
- Page 15 Operating Instruction Manual: Serial Numbers: OM-HTWP-ELECTRIC-01 From: BP5141 5.8 System Leak Test & Function Test NOTE: These tests are performed as part of the process detailed in section 5.7 and need not be repeated if the full process described in section 5.7 has been performed. Low-Pressure Leak Test &...
-
Page 16: Operation
From: BP5141 6.0 Operation Hi-Force HTWP Electric Torque Wrench Pumps are used to power double-acting Hydraulic Torque Wrenches. Make sure you read this manual in conjunction with the Torque Wrench’s operating instruction manual to ensure correct and safe operation of all hydraulic equipment in the system. - Page 17 Operating Instruction Manual: Serial Numbers: OM-HTWP-ELECTRIC-01 From: BP5141 6.2. Setting the Pressure (Torque) Before setting the pump pressure it is necessary to determine what pump pressure will result in the torque value required. Use the tool-specific pressure-torque conversion chart provided with the torque wrench to determine the pump pressure that corresponds to the required torque value.
- Page 18 From: BP5141 6.3. Pump Operation Hi-force recommends that operation of the pump/wrench combination be a minimum 2 person job, one to operate the pump and one to operate the wrench. An additional operator will be required for each addition wrench connected to the pump.
-
Page 19: Maintenance And Storage
Routinely perform a visual inspection of the pump and electric cables for signs of damage. Any electrical cables showing signs of damage MUST be replaced by a Hi-Force authorised repair centre, or by a competent electrician. ... -
Page 20: Pressure Conversion Table
Operating Instruction Manual: Serial Numbers: OM-HTWP-ELECTRIC-01 From: BP5141 10.0 Pressure Conversion Table kgf / cm kgf / cm 10.2 5221 367.1 20.4 5366 377.3 30.6 5511 387.5 40.8 5656 397.7 51.0 5802 407.9 61.2 5947 418.1 1015 71.4 6092 428.3 1160 81.6 6237... -
Page 21: Troubleshooting
Serial Numbers: OM-HTWP-ELECTRIC-01 From: BP5141 11.0 Troubleshooting Hi-Force HTWP Electric Torque Wrench Pumps should be serviced and repaired only by authorised Hi- Force repair centres. The following table gives possible causes and solutions for common problems. TROUBLESHOOTING GUIDE Problem Possible Cause Solution 1. - Page 22 Make sure the tool is correctly rated for the capacity. application. 10. Erratic tool a. Leakage from pump or valve Contact your local Hi-Force office / distributor. movement. internal components. b. Internal leak, due to damaged/worn Contact your local Hi-Force office / distributor.
- Page 23 Operating Instruction Manual: Serial Numbers: OM-HTWP-ELECTRIC-01 From: BP5141 UK Head Office: Hi-Force Limited Prospect Way, Daventry, Northamptonshire NN11 8PL United Kingdom Tel: + 44 1327 301000 Fax: + 44 1327 706555 Email: daventry@hi-force.com www.hi-force.com GLOBAL BRAND. LOCAL SERVICE. Hi-Force Global offices: www.hi-force.com/en-uk/hi-force-offices...
