This 'original instructions' document assumes that the operator carrying out any operation with this
product is trained and competent to do so. This manual does not attempt to cover all details or variations
in the equipment. Nor does this manual claim to provide for every possible contingency met in connection
with the installation, operation, or maintenance thereof. Should further information be desired, or should
a particular problem arise which is not covered in sufficient detail, the matter should be referred to
Hi-Force.
OPERATING INSTRUCTION MANUAL
HEP1 SERIES | ELECTRIC DRIVEN MINI PUMPS
Hi-Force HEP1 series Electric Driven Hydraulic Pumps are designed to operate high pressure hydraulic
cylinders and tools with a maximum working pressure of 700Bar. This manual applies to the Hi-Force
HEP1 series, Electric Driven Hydraulic Pumps. It contains the latest product information available at the
time of publication and approval. Hi-Force reserves the right to make changes to this document at any
time without notice.
Operating Instruction Manual:
OM-HEP1-01
1
From Serial Number:
ALL
Advertisement
Table of Contents
Related Manuals for Hi-Force HEP1 Series
Summary of Contents for Hi-Force HEP1 Series
- Page 1 700Bar. This manual applies to the Hi-Force HEP1 series, Electric Driven Hydraulic Pumps. It contains the latest product information available at the time of publication and approval. Hi-Force reserves the right to make changes to this document at any time without notice.
-
Page 2: Table Of Contents
Operating Instruction Manual: From Serial Number: OM-HEP1-01 Table of Contents 1.0 Inspection upon Receipt ..................3 2.0 Safety Precautions ....................3 2.1 Introduction ......................3 2.2 Work Area Safety ....................3 2.3 General Hydraulic System Safety Precautions ..........3 2.4 Hydraulic Pump Specific Safety Precautions ........... 4 3.0 Declaration of Incorporation / Conformity ............ -
Page 3: Inspection Upon Receipt
If in doubt on the correct use of any Hi-Force equipment, contact your nearest Hi-Force office or distributor. Only qualified personnel should be allowed to operate hydraulic equipment. If an operator has not been trained on high-pressure hydraulic equipment and its safe usage, consult your local Hi-Force sales office or distributor who can offer training courses for operators. -
Page 4: Hydraulic Pump Specific Safety Precautions
NEVER exceed the maximum rated capacity of any hydraulic cylinder/tool. Hi-Force manufactures its hydraulic pumps to operate at a maximum working pressure of 700 BAR (10,000 PSI). DO NOT connect a cylinder/tool with a lower pressure capacity rating to any Hi-Force pump of this model series. -
Page 5: Declaration Of Incorporation / Conformity
3.0 Declaration of Incorporation / Conformity Hi-Force declares that this product has been tested and complies with the standards set out in the relevant EU directives. The EU Declaration of Incorporation / Conformity is included as Annex A to this instruction document and is supplied with all shipments of this product. -
Page 6: Component Identification
(or extended for pulling cylinders) Stand pump vertically on end of oil reservoir. Remove filler plug (5) and check that oil level. Replenish as required with Hi-Force HFO46 oil. Replace plug and tighten firmly taking care not to damage O-ring. -
Page 7: Filling The Pump With Oil
NOTE: Supply voltages vary from country to country. Hi-Force pumps will operate within the normal voltage tolerance ranges, but in extreme cases where they are operated for long periods at high pressures and in low voltage conditions, the motor may overheat and shut down. -
Page 8: Operation
ON button once more to build up pressure again. 7.0 Maintenance Use only Hi-Force HFO46 oil to keep the reservoir topped up. Ensure that connected cylinders are fully retracted before checking oil level otherwise reservoir may become pressurised and damaged. - Page 9 Low oil level. Add oil as per section 5.2. c. External oil leak in system. Contact your local Hi-Force office/distributor. 4. Noisy Operation a. Air trapped in the system. Bleed air from the system as per section 5.5 b.
- Page 10 Operating Instruction Manual: From Serial Number: OM-HEP1-01 Head Office: Hi-Force Limited Prospect Way, Daventry Northamptonshire NN11 8PL United Kingdom Tel: + 44 1327 301000 | Fax: + 44 1327 706555 www.hi-force.com Regional Offices: For information on our offices worldwide, scan the below QR code...
