OPERATING INSTRUCTION MANUAL
TPA-A SERIES | AIR DRIVEN TORQUE WRENCH PUMPS
Hi-Force TPA series Air Driven Torque Wrench Pumps are premium pumps designed for use with Hi-Force
Hydraulic Torque Wrenches. TPA Pumps can be used to power up to 4 torque wrenches simultaneously
(all operating at the same pressure). Output pressure is fully adjustable and can be set to any value up to
a maximum working pressure of 700 bar (10,000 psi). This manual applies to the Hi-Force TPA series
Analogue Air Driven Torque Wrench Pumps Only. It contains the latest product information available at the
time of publication and approval. For information relating to the servicing of an Air Driven Torque Wrench
Pump, see the servicing instructions, which are available on the Hi-Force website. Hi-Force reserves the
right to make changes to this document at any time without notice.
Operating Instruction Manual:
OM-TPA-A-01
- PREMIUM LINE (ANALOGUE)
1
Serial Numbers:
All
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hi-Force Premium TPA-A Series
Summary of Contents for Hi-Force Premium TPA-A Series
- Page 1 (all operating at the same pressure). Output pressure is fully adjustable and can be set to any value up to a maximum working pressure of 700 bar (10,000 psi). This manual applies to the Hi-Force TPA series Analogue Air Driven Torque Wrench Pumps Only. It contains the latest product information available at the time of publication and approval.
-
Page 2: Table Of Contents
Operating Instruction Manual: Serial Numbers: OM-TPA-A-01 Table of Contents 1.0 Inspection upon Receipt ..............3 2.0 Safety Precautions ................3 3.0 Declaration of Incorporation / Conformity ........6 4.0 Component Identification ..............7 5.0 Installation / Setup ................10 6.0 Operation ..................18 7.0 Maintenance and Storage .............. -
Page 3: Inspection Upon Receipt
If in doubt on the correct use of any Hi-Force equipment, contact your nearest Hi-Force office or distributor. Only qualified personnel should be allowed to operate hydraulic equipment. If an operator has not been trained on high-pressure hydraulic equipment and its safe usage, consult your local Hi-Force sales office or distributor who can offer training courses for operators. - Page 4 NEVER attempt to solve, or clean-up leaks in the system while the system is pressurised. Immediately replace any worn or damaged parts using genuine Hi-Force parts only. DO NOT use any hydraulic equipment if you are under the influence of alcohol, drugs or medication.
- Page 5 NEVER exceed the maximum rated pressure of any hydraulic equipment. Hi-Force manufactures its TPA hydraulic pumps to operate at a maximum working pressure of 700 bar (10,000 psi). DO NOT connect hydraulic torque equipment with a lower pressure capacity rating to any Hi-Force pump of this model series.
-
Page 6: Declaration Of Incorporation / Conformity
3.0 Declaration of Incorporation / Conformity Hi-Force declares that this product has been tested and complies with the standards set out in the relevant EU directives. The EU Declaration of Incorporation / Conformity is included as Annex A to this instruction... -
Page 7: Component Identification
Operating Instruction Manual: Serial Numbers: OM-TPA-A-01 4.0 Component Identification Oil Reservoir Oil Pressure Gauge Air Motor Multi-Outlet 4-Way Split-Block Air Motor Muffler Oil Temperature / Pressure Gauge FRL Unit (See Figure 4.3) See section 5.4 Figure 4.1: Component Identification... - Page 8 Operating Instruction Manual: Serial Numbers: OM-TPA-A-01 Tool Retract Coupler (90 bar) Control Pendant Inlet Adjustable Pressure Relief Valve with Tool Advance Coupler (700 bar) Locking Wing Nut Roll Frame Control Pendant Oil Filler / Breather Cap Figure 4.2: Component Identification...
- Page 9 Operating Instruction Manual: Serial Numbers: OM-TPA-A-01 Air Lubricator Reservoir Air Supply Inlet (3/8” BSP) Air Pressure Gauge Air Filter Water Trap Air Lubricator Filler Plug Water Trap Drain Button Air Lubricator Control Knob Water Trap Drain Port Air Regulator Control Knob Oil Reservoir Drain Plug Figure 4.3: Component Identification...
-
Page 10: Installation / Setup
Operating Instruction Manual: Serial Numbers: OM-TPA-A-01 5.0 Installation / Setup 5.1 Before First Use / Preparation 1. Immediately after unpacking, examine the unit for signs of transit damage and if found contact the shipping company. 2. Establish the oil level in the oil reservoir (1) using the oil level gauge (7). Depending on the shipping method used, the reservoir may either be supplied full or empty. - Page 11 Make sure both coupler halves are clean before connecting. If you are NOT using a Hi-Force Torque Wrench with the pump, or if the wrench or hoses have been modified, make sure that the wrench is connected correctly so that the male high-pressure advance coupler (9) is connected to the advance port on the tool.
- Page 12 Operating Instruction Manual: Serial Numbers: OM-TPA-A-01 5.3.3. Connecting a Torque Wrench to the Pump Connect the female coupler on the red hose to the male advance coupler (9) on the pump. Connect the male coupler on the black hose to the female retract coupler (8) on the pump. Figure 5.3: Connecting to the Pump ...
- Page 13 OM-TPA-A-01 5.4 Connection of Additional Torque Wrenches Hi-Force TPA-A Pumps are equipped with additional ports allowing for up to 4 Torque wrenches to be driven simultaneously (all operating at the same pressure). This feature can be useful for even tightening of large joints. However, it must be noted that multiple torque wrenches will operate slower than a single torque wrench would, so this is not necessarily a time-saving method.
- Page 14 Operating Instruction Manual: Serial Numbers: OM-TPA-A-01 5.5 Filling the Air Supply Lubricant Reservoir IMPORTANT: The TPA-A Series Air Motors require ISO VG 32 (SAE10) Detergent Oil. Turn Off or Disconnect from the Air Supply. Remove the Air Lubricator Filler Plug (17). ...
- Page 15 DO NOT TOUCH. NOTE: When longer hoses are used (greater than 5m), the above procedure may not remove all the air from the system. In these cases, contact your Hi-Force representative for advice on pre-filling hoses with hydraulic oil. ...
- Page 16 Operating Instruction Manual: Serial Numbers: OM-TPA-A-01 Visually inspect the system for leaks. (High-Pressure leak & function test) With the air motor running the retract hose/s still contains 80-90 bar pressure. DO NOT TOUCH. Switch off the pump unit by pressing the ‘Stop’ button (see figure 5.6) on the control pendant (14) and check the tool and connections for any leaks.
- Page 17 Operating Instruction Manual: Serial Numbers: OM-TPA-A-01 5.11 System Leak Test & Function Test NOTE: These tests are performed as part of the process detailed in section 5.10 and need not be repeated if the full process described in section 5.10 has been performed. Low-Pressure Leak Test IMPORTANT: A system leak test should be performed each time a coupler/s is disconnected and new...
-
Page 18: Operation
OM-TPA-A-01 6.0 Operation Hi-Force TPA-A Torque Wrench Pumps are used to power double-acting Hydraulic Torque Wrenches. Make sure you read this manual in conjunction with the Torque Wrenches operating instruction manual to ensure correct and safe operation of all hydraulic equipment in the system. - Page 19 Operating Instruction Manual: Serial Numbers: OM-TPA-A-01 6.2. Setting the Pressure (Torque) Before setting the pump pressure it is necessary to determine what pump pressure will result in the torque value required. Use the tool-specific pressure-torque conversion chart provided with the torque wrench to determine the pump pressure that corresponds to the required torque value.
- Page 20 All operating functions of the pump are performed via the 2 buttons on the control pendant (14). (See figure 6.2) Hi-force recommends that operation of the pump/wrench combination be a minimum 2 person job, one to operate the pump and one to operate the wrench. An additional operator will be required for each addition wrench connected to the pump.
-
Page 21: Maintenance And Storage
Operating Instruction Manual: Serial Numbers: OM-TPA-A-01 7.0 Maintenance and Storage Carry out basic maintenance on a regular basis to keep the pump operating in a trouble-free manner. Maintenance intervals are determined by the frequency of use and the operating conditions on site. ... -
Page 22: Specifications
(3). 9.0 System Components / Accessories (Refer to the Hi-Force website or latest Hi-Force catalogue, for further details) HTWH Series High-Pressure Hydraulic Hoses (Up to 100m). -
Page 23: Pressure Conversion Table
Operating Instruction Manual: Serial Numbers: OM-TPA-A-01 10.0 Pressure Conversion Table kgf / cm kgf / cm 10.2 5221 367.1 20.4 5366 377.3 30.6 5511 387.5 40.8 5656 397.7 51.0 5802 407.9 61.2 5947 418.1 1015 71.4 6092 428.3 1160 81.6 6237 438.5 1305... -
Page 24: Troubleshooting
Operating Instruction Manual: Serial Numbers: OM-TPA-A-01 11.0 Troubleshooting Hi-Force TPA-A Torque Wrench Pumps should be serviced and repaired only by authorised Hi-Force repair centres. The following table gives possible causes and solutions for common problems. TROUBLESHOOTING GUIDE Problem Possible Cause Solution 1. - Page 25 Problem Possible Cause Solution 8. Erratic tool movement. a. Leakage from pump or valve Contact your local Hi-Force office / distributor. internal components. b. Internal leak, due to damaged/worn Contact your local Hi-Force office / distributor. seals or valves. c. Oil level too low.
-
Page 26: Contact Details
Operating Instruction Manual: Serial Numbers: OM-TPA-A-01 UK Head Office: Hi-Force Limited Prospect Way, Daventry, Northamptonshire NN11 8PL United Kingdom Tel: + 44 1327 301000 Fax: + 44 1327 706555 Email: daventry@hi-force.com... - Page 27 Baku Milano Azerbaijan Italy Tel: +994 124 474 100 Tel: +39 0257 607 174 Email: baku@hi-force.com Email: italy@hi-force.com Hi-Force Hydraulics (Asia) S.B. Hi-Force Nederland B.V. Selangor Numansdorp Malaysia Netherlands Tel: +603 5525 4203 Tel: +31 85 902 8111 Email: malaysia@hi-force.com Email: holland@hi-force.com...
