Summary of Contents for liniLED Top Power Colour
- Page 1 LED strip manual liniLED® Top Power Colour 30 mm V DC ADAM IK08 RoHS IP40/IP68 CLEANING AGENTS FROST SEA WATER SWIMMING POOL UV RESISTANT SWIMMING POOL System GLOW WIRE BEND RADIUS S D C M RESISTANT RESISTANT RESISTANT ENVIRONMENT SUBMERSIBLE 850 °C...
-
Page 3: Table Of Contents
Top Power Colour Technical notes Top Power Colour - Product drawings Product information Product specifications Cable selection Area advice Product care and handling Cutting instructions Solder Connect IP40 Uninstalling the connector Power supply Welded connector Symbols... -
Page 4: Technical Notes
- Products are transported in proper packaging. Products should remain packed until installation. - Take ESD (Electrostatic Discharge) protection measures when handling liniLED® products. - The products and their components may not be exposed to mechanical, static loads and other tension/compression other than from the product itself. -
Page 5: Top Power Colour - Product Drawings
Product information The liniLED® Top Power LED strip IP40 (IP68*) is a high quality, flexible LED strip, with a unique co-extrusion technology. The combination of high quality and exceptional flexibility, allows for an endless range of indoor and outdoor applications. -
Page 6: Cable Selection
2.50 mm2 - 0.007 Ω/m 310.2 m 601.6 m 151.9 m 297.5 m 56.9 m 115.1 m 25.2 m 54.3 m Note: Calculations are based on a standard connector with 1 metre cable (0.5 mm2). LED strip manual | liniLED® Top Power Colour... -
Page 7: Area Advice
Area advice Depending on the installation area of the liniLED® LED strip we off er a range of IP40, IP67 and IP68 solutions to cope with external factors. Below the diff erent connectors are displayed for use in diff erent environments. See corresponding pages or individual product manual for further instructions. -
Page 8: Product Care And Handling
Do not twist the LED strip. The LED strip has to be unreeled on a horizontal surface at the time of installation. Do not unreel the spool of LED strip before installation. LED strip manual | liniLED® Top Power Colour... -
Page 9: Cutting Instructions
Top view | Make sure the cut is vertical as illustraded in the image above. above. Top view | Only cut on the dotted lines to prevent damaging the LED Dispose of the unnecessary material through waste recycling of strip. electrical and electronic equipment. LED strip manual | liniLED® Top Power Colour... - Page 10 Cutting instructions Place the liniLED® LED strip on the base of the cutting tool. Not doing so may result in a deformed LED strip. LED strip manual | liniLED® Top Power Colour...
-
Page 11: Solder
PCB. Carefully cut away this part of the extrusion. Side view | Do not cut the PCB! The end result after cutting the LED strip extrusion should look similar to the image above. LED strip manual | liniLED® Top Power Colour... - Page 12 Pre-solder the connector pads. Pre-solder the wires. 300°C Max. 4 sec. Solder the wires to the connector pads. Connect the liniLED® LED strip to the power supply (24 V DC) con- stant voltage. LED strip manual | liniLED® Top Power Colour...
-
Page 13: Connect Ip40
The liniLED® IP40 Connector consists of: End cap (1), Shell (2), Take into account the direction of the arrow on the bottom of the Connector (3), Clamp (4). liniLED® LED strip and allign it with the arrow on the clamp (4). Side view | Slide the clamp Place the shell over the LED strip. - Page 14 (4). arrow is on the upper side. ‘ Click ’ Test the liniLED® LED strip before you slide it fully over the clamp (4). Slide the shell entirely over the clamp and push firmly until it ‘clicks‘...
-
Page 15: Uninstalling The Connector
Uninstalling the connector Firmly grab the outer shell and gently grab the liniLED® LED strip. Gently wiggle the connector and pull in opposite direction. The connector should look like this when it is removed. Firmly press the sides of the shell and pull gently while holding the cable to remove it. -
Page 16: Power Supply
Measure output (23-25 V DC) before installing liniLED® system Connect the LED strip as indicated in the figure above. The wires should be connected as follows: Red (+) and Black (-). Insert the power plug. LED strip manual | liniLED® Top Power Colour... -
Page 17: Welded Connector
Welded connector Option 1 Glued profile | Please do not try to remove the U-profi le Option 2 Pre-installed | The liniLED® Welded connector and LED because this damages the connector. strip are pre-installed in a fi xture/profi le. After installation Option 3 Removable sleeve | The U-profi le can be removed after installation, but this will void warranty. -
Page 18: Symbols
This product is available on request and can be applied submerged in swimming pools and their environment. Disinfectants will have no harmful e ect on the product. For chemical speci cations of these elements see the liniLED® material sheet. Verify IP rating for proper use. - Page 19 Disclaimer The published information is checked to be as accurate as possible, however Triolight B.V. or any reseller of liniLED® cannot be held liable for any damages resulting from misprints, errors, modifi cations or outdated information. No legal rights can be derived from this document. Triolight B.V. reserves the right to modify the information without informing the customers.
