LED strip manual
liniLED® Side TWW/TW 1200
5
R
3
CRI
24
MAC
F
30 mm
80
+
V DC
ADAM
IK08
RoHS
IP40/IP68
CLEANING AGENTS
FROST
SEA WATER
SWIMMING POOL
UV RESISTANT
SWIMMING POOL
System
GLOW WIRE
BEND RADIUS
S D C M
RESISTANT
RESISTANT
RESISTANT
ENVIRONMENT
SUBMERSIBLE
850 °C
V301220

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Side TWW 1200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for liniLED Side TWW 1200

  • Page 1 LED strip manual liniLED® Side TWW/TW 1200 30 mm V DC ADAM IK08 RoHS IP40/IP68 CLEANING AGENTS FROST SEA WATER SWIMMING POOL UV RESISTANT SWIMMING POOL System GLOW WIRE BEND RADIUS S D C M RESISTANT RESISTANT RESISTANT ENVIRONMENT SUBMERSIBLE 850 °C...
  • Page 2: Table Of Contents

    Side TWW/TW 1200 Technical notes Technical specifications Product drawings Maximum cable length Area advice Product care and handling Cutting instructions Solder Connect IP40 Uninstalling the connector Welded connector Power and connection diagram 15 Symbols...
  • Page 3: Technical Notes

    - Products are transported in proper packaging. Products should remain packed until installation. - Take ESD (Electrostatic Discharge) protection measures when handling liniLED® products. - The products and their components may not be exposed to mechanical, static loads and other tension/compression other than from the product itself.
  • Page 4: Technical Specifications

    Max. connection length between -30°C and -20°C is 6.3 metres. Both channels @ 100% = 4000K (TW) / 2700K (TWW) UL certification allows an operable length of TWW; max 8.4 m. Products drawings 12.5 Manual | liniLED® Side TWW/TW 1200...
  • Page 5: Maximum Cable Length

    Note: Calculations are based on a standard connector with 1 metre cable (0.5 mm2). 2.50 mm2 - 0.007 Ω/m 103.6 m 204.9 m 48.6 m 99.2 m 30.3 m 64.0 m 18.0 m 40.5 m 2700K-6500K TW 3000 Colour temperature Manual | liniLED® Side TWW/TW 1200 LED strip length...
  • Page 6: Area Advice

    Area advice Depending on the installation area of the liniLED® LED strip we off er a range of IP20, IP40 and IP68 solutions to cope with external factors. Below the diff erent connectors are displayed for use in diff erent environments. See corresponding pages or individual product manual for further instructions.
  • Page 7: Product Care And Handling

    Do not bend the LED strip sidewards. Do not twist the LED strip. The LED strip has to be unreeled on a horizontal surface at the time of installation. Do not unreel the spool of LED strip before installation. Manual | liniLED® Side TWW/TW 1200...
  • Page 8: Cutting Instructions

    Top view | Make sure the cut is vertical as illustraded in the image above. above. Top view | Only cut on the dotted lines to prevent damaging the Dispose of the unnecessary material through waste recycling of LED strip. electrical and electronic equipment. Manual | liniLED® Side TWW/TW 1200...
  • Page 9 Cutting instructions Place the liniLED® LED strip on the base of the cutting tool. Not doing so may result in a deformed LED strip. Manual | liniLED® Side TWW/TW 1200...
  • Page 10: Solder

    Isometric view | Only cut the LED strip extrusion on the dotted line Isometric view | Do not cut the PCB! of the extrusion to prevent damaging the PCB. Carefully cut away this part of the extrusion. Manual | liniLED® Side TWW/TW 1200...
  • Page 11 300°C | Max. 4 sec. 300°C Max. 4 sec. Pre-solder the wires. Solder the wires to the connector pads. 300°C | Max. 4 sec. Connect the liniLED® LED strip to the power supply (24 V DC) constant voltage. Manual | liniLED® Side TWW/TW 1200...
  • Page 12: Connect Ip40

    Take into account the direction of the arrow on the bottom of the Connector (3), Clamp (4). liniLED® LED strip and allign it with the arrow on the clamp (4). Place the shell over the LED strip. Make sure the side with the...
  • Page 13 ‘ Click ’ Slide the shell entirely over the clamp and push firmly until it Test the liniLED® LED strip before you slide it fully over the clamp (4). ‘clicks‘ . Finish the connection by inserting an end cap in the hollow chamber on the end side of the liniLED®...
  • Page 14: Uninstalling The Connector

    Uninstalling the connector Firmly grab the outer shell and gently grab the liniLED® LED strip. Gently wiggle the connector and pull in opposite direction. The connector should look like this when it is removed. Firmly press the sides of the shell and pull gently while holding the cable to remove it.
  • Page 15: Welded Connector

    Welded connector Option 1 Glued profile | Please do not try to remove the U-profi le Option 2 Pre-installed | The liniLED® Welded connector and LED because this damages the connector. strip are pre-installed in a fi xture/profi le. Option 3 Removable sleeve | The U-profi le can be removed after installation, but this will void warranty.
  • Page 16 Turn off the power before connecting the LED strip to the power 230 V Power 24 V liniLED® Supply Control Measure output (23-25 V DC) before installing liniLED® system Connect the LED strip as indicated in the figure above. Insert the power plug. Manual | liniLED® Side TWW/TW 1200...
  • Page 17: Symbols

    This product is available on request and can be applied submerged in swimming pools and their environment. Disinfectants will have no harmful e ect on the product. For chemical speci cations of these elements see the liniLED® material sheet. Verify IP rating for proper use.
  • Page 18 Disclaimer The published information is checked to be as accurate as possible, however Triolight B.V. or any reseller of liniLED® cannot be held liable for any damages resulting from misprints, errors, modifi cations or outdated information. No legal rights can be derived from this document. Triolight B.V. reserves the right to modify the information without informing the customers.
  • Page 19 Manual | liniLED® Side TWW/TW 1200...
