- Page 1 Manual liniLED® Diffuse 150 mm ADAM V DC IP68 IK08 RoHS IP69K CLEANING FROST POOL CL SWIMMING POOL System GLOW WIRE S D C M BEND RADIUS SUBMERSIBLE 850 °C...
-
Page 3: Table Of Contents
Diffuse Technical notes Top Diffuse 12 Product drawings Technical specifications Top Diffuse 18 Product drawings Technical specifications Side Diffuse Product drawings Technical specifications Product care and handling Area advice Connectors Installation Cable selection Power supply Symbols... -
Page 4: Technical Notes
- Products are transported in proper packaging. Products should remain packed until installation. - Take ESD (Electrostatic Discharge) protection measures when handling liniLED® products. - The products and their components may not be exposed to mechanical, static loads and other tension/compression other than from the product itself. - Page 5 IP68+ > 50 m/IP69K Storage temperature -30°C ... 55°C Operating temperature -30°C ... 55°C1 Minimal bending radius 150 mm Dimensions 12x18 mm Weight 240 gram per metre Max. connection length between -30°C ... -20°C is 7 metres. Manual | liniLED® Diffuse...
-
Page 6: Product Drawings
IP68+ > 50 m/IP69K Storage temperature -30°C ... 55°C Operating temperature -30°C ... 55°C1 Minimal bending radius 150 mm Dimensions 18x18 mm Weight 340 gram per metre Max. connection length between -30°C ... -20°C is 7 metres. Manual | liniLED® Diffuse... - Page 7 IP68+ > 50 m/IP69K Storage temperature -30°C ... 55°C Operating temperature -30°C ... 55°C1 Minimal bending radius 150 mm Dimensions 12x18 mm Weight 240 gram per metre Max. connection length between -30°C ... -20°C is 7 metres. Manual | liniLED® Diffuse...
-
Page 8: Top Diffuse
The direction of bending, the radius of the bend and general handling instructions are explained on this page. Top Diffuse Top Diffuse Solely bend the liniLED® Top Diffuse LED strip in up- and downward direction Do not bend the liniLED®Top Diffuse LED strip in sideward direction when when the light surface is facing upwards. -
Page 9: Connectors
Connectors The liniLED® Diffuse LED strips come with a pre-assembled connector, available in different types. Extending LED strip can be achieved with the liniLED® Diffuse Extension Cord. Below is an overview of the available types with corresponding cable lengths and article numbers. -
Page 10: Installation
Make sure the power is OFF when you start the installation. Unspool the LED strip on a horizontal surface. Make sure the liniLED® Diffuse LED strip and the U-Profile are aligned. Gently push the liniLED® Diffuse LED strip into the U-Profile. - Page 11 (highlighted in orange in the image above). Male Female Female Male Optional Align the white marker of the Female and Male connector. Optional - Snap the connector while keeping the white marker aligned. Turn the power ON. Manual | liniLED® Diffuse...
-
Page 12: Cable Selection
16.9 m 2.50 mm2 - 0.007 Ω/m 174.0 m 340.0 m 83.7 m 166.7 m 29.6 m 62.8 m 11.6 m 28.2 m Note: Calculations are based on a standard connector with 1 metre cable (0,5 mm2). Manual | liniLED® Diffuse... -
Page 13: Power Supply
Power supply 230 V AC Power Supply 24 V DC liniLED® Control solution (optional) IP68+/IP69K IP68+/IP69K IP68+/IP69K Manual | liniLED® Diffuse... -
Page 14: Symbols
Dust-tight, no ingress of dust. Protected against the effects of continuous immersion in water IP68 (immersion in water at a maximum depth of 50 metres). Only in combination with the liniLED® Mirror Welded Connector. Dust- tight, no ingress of dust. Protected against close-range high pressure, high temperature spray downs. - Page 15 Disclaimer The published information is checked to be as accurate as possible, however Triolight B.V. or any reseller of liniLED® cannot be held liable for any damages resulting from errors or outdated information. Triolight B.V. reserves the right to modify the information without informing the customers. When this document is printed or downloaded, please check for the latest version on the internet, the most up to date information will be published on www.liniLED.com.
