LED strip manual
liniLED® Top Mono White G1 & G4
5
R
2
CRI
24
MAC
F
30 mm
80
+
V DC
ADAM
IK08
RoHS
IP40/IP68
CLEANING AGENTS
FROST
SEA WATER
SWIMMING POOL
SWIMMING POOL
UV RESISTANT
System
GLOW WIRE
S D C M
BEND RADIUS
RESISTANT
RESISTANT
RESISTANT
ENVIRONMENT
SUBMERSIBLE
850 °C

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Top Mono White G1 and is the answer not in the manual?

Questions and answers

Summary of Contents for liniLED Top Mono White G1

  • Page 1 LED strip manual liniLED® Top Mono White G1 & G4 30 mm V DC ADAM IK08 RoHS IP40/IP68 CLEANING AGENTS FROST SEA WATER SWIMMING POOL SWIMMING POOL UV RESISTANT System GLOW WIRE S D C M BEND RADIUS RESISTANT RESISTANT...
  • Page 2: Table Of Contents

    Top Mono White Technical notes Technical specifications | Deco G1 Technical specifications | Power G1 Technical specifications | High power G4 Maximum cable length | Deco G1 Maximum cable length | Power G1 Maximum cable length | High Power G4...
  • Page 3: Technical Notes

    - Products are transported in proper packaging. Products should remain packed until installation. - Take ESD (Electrostatic Discharge) protection measures when handling liniLED® products. - The products and their components may not be exposed to mechanical, static loads and other tension/compression other than from the product itself.
  • Page 4: Technical Specifications | Deco G1

    30 mm Typical measured values are given, which due to tolerances in components and production process can vary up to 10%. Max. connection length between -30°C and -20°C is 14 metres. Product drawing 14.29 Manual | liniLED® Top Mono White...
  • Page 5: Technical Specifications | Power G1

    30 mm Typical measured values are given, which due to tolerances in components and production process can vary up to 10%. Max. connection length between -30°C and -20°C is 7 metres. Product drawing 14.29 Manual | liniLED® Top Mono White...
  • Page 6: Technical Specifications | High Power G4

    Typical measured values are given, which due to tolerances in components and production process can vary up to 10%. Max. connection length between -30°C and -20°C is 7 metres. Product drawing Product drawing 8.33 Manual | liniLED® Top Mono White...
  • Page 7: Maximum Cable Length | Deco G1

    2.50 mm2 - 0.007 Ω/m 963.4 m 1855.7 m 187.5 m 366.0 m 90.5 m 179.7 m 42.0 m 86.6 m Note: Calculations are based on a standard connector with 1 metre cable (0.5 mm2). Manual | liniLED® Top Mono White...
  • Page 8: Maximum Cable Length | Power G1

    2.50 mm2 - 0.007 Ω/m 391.4 m 757.5 m 192.5 m 375.5 m 73.1 m 146.3 m 33.3 m 69.9 m Note: Calculations are based on a standard connector with 1 metre cable (0.5 mm2). Manual | liniLED® Top Mono White...
  • Page 9: Maximum Cable Length | High Power G4

    2.50 mm2 - 0.007 Ω/m 215.2 m 419.2 m 104.4 m 206.3 m 37.9 m 78.6 m 15.7 m 36.1 m Note: Calculations are based on a standard connector with 1 metre cable (0.5 mm2). Manual | liniLED® Top Mono White...
  • Page 10: Area Advice

    Area advice Depending on the installation area of the liniLED® LED strip we off er a range of IP40, IP67 and IP68 solutions to cope with external factors. Below the diff erent connectors are displayed for use in diff erent environments. See corresponding pages or individual product manual for further instructions.
  • Page 11: Product Care And Handling

    Do not bend the LED strip sidewards. Do not twist the LED strip. The LED strip has to be unreeled on a horizontal surface at the time of installation. Do not unreel the spool of LED strip before installation. Manual | liniLED® Top Mono White...
  • Page 12: Cutting Instructions

    Turn off the power. Make sure the wires are not under electric image above. current. Isometric view | Make sure the cut is vertical as illustraded in the Top view | Make sure the cut is vertical as illustraded in the image image above. above. Manual | liniLED® Top Mono White...
  • Page 13: Solder

    Isometric view | Only cut the LED strip extrusion on the dotted line Isometric view | Do not cut the PCB! of the extrusion to prevent damaging the PCB. Carefully cut away this part of the extrusion. Manual | liniLED® Top Mono White...
  • Page 14 Pre-solder the connector pads. similar to the image above. 300°C Max. 4 sec. Pre-solder the wires. Solder the wires to the connector pads. Connect the liniLED® LED strip to the power supply (24 V DC) constant voltage. Manual | liniLED® Top Mono White...
  • Page 15: Connect Ip40

    Take into account the direction of the arrow on the bottom of the connector (3), clamp (4). liniLED® LED strip and allign it with the arrow on the clamp (4). Place the shell over the LED strip. Make sure the side with the...
  • Page 16 (4). arrow is on the upper side. ‘ Click ’ Test the liniLED® LED strip before you slide it fully over the clamp Slide the shell entirely over the clamp and push fi rmly until it (4).
  • Page 17: Uninstalling The Connector

    Uninstalling the connector Firmly grab the outer shell and gently grab the liniLED® LED strip. Gently wiggle the connector and pull in opposite direction. The connector should look like this when it is removed. Firmly press the sides of the shell and pull gently while holding the cable to remove it.
  • Page 18: Welded Connector

    Welded connector Option 1 Glued profile | Please do not try to remove the U-profi le Option 2 Pre-installed | The liniLED® Welded connector and LED because this damages the connector. strip are pre-installed in a fi xture/profi le. After installation Option 3 Removable sleeve | The U-profi le can be removed after installation, but this will void warranty.
  • Page 19: Power And Connection Diagram

    Turn off the power before connecting the LED strip to the power. liniLED® Control 230 V Power 24 V Supply (Optional) Measure output (23-25 V DC) before installing liniLED® system Connect the LED strip as indicated in the figure above. Insert the power plug. Manual | liniLED® Top Mono White...
  • Page 20: Symbols

    This product is available on request and can be applied submerged in swimming pools and their environment. Disinfectants will have no harmful e ect on the product. For chemical speci cations of these elements see the liniLED® material sheet. Verify IP rating for proper use.
  • Page 21 Disclaimer The published information is checked to be as accurate as possible, however Triolight B.V. or any reseller of liniLED® cannot be held liable for any damages resulting from misprints, errors, modifi cations or outdated information. No legal rights can be derived from this document. Triolight B.V. reserves the right to modify the information without informing the customers.
  • Page 24 Triolight B.V. Subject to misprints, errors and modifications. No legal rights can be derived from this document. V301220...
