- Page 1 LED strip manual liniLED® PCB Deco White 20 mm IP00 RoHS System BEND RADIUS...
-
Page 3: Table Of Contents
LED strip PCB Deco White Technical notes Product codes & characteristics Cable selection Area advice Product care and handling Cutting instructions Solder Connect IP20 Power supply... -
Page 4: Technical Notes
- Products are transported in proper packaging. Products should remain packed until installation. - Take ESD (Electrostatic Discharge) protection measures when handling liniLED® products. - The products and their components may not be exposed to mechanical, static loads and other tension/compression other than from the product itself. -
Page 5: Product Codes & Characteristics
Storage temperature -30 °C .. 85 °C -30 °C .. 55 °C1 Operation temperature Minimal bending radius 20 mm 1 Max. connection length between -20 °C and -30 °C is 14 metres. LED strip manual | liniLED® PCB Deco White... -
Page 6: Cable Selection
2.50 mm2 - 0.007 Ω/m 698.9 m 1347.8 m 134.6 m 264.4 m 64.1 m 128.9 m 28.8 m 61.2 m Note: Calculations are based on a standard connector with 1 metre cable (0.5 mm2). LED strip manual | liniLED® PCB Deco White... -
Page 7: Area Advice
Area advice Depending on the area where the liniLED® LED strip is installed we off er a range of solutions to cope with external factors. The product portfolio for the liniLED® PCB LED strip includes a IP20 connector. Indoor environment | (IP20) | liniLED®... -
Page 8: Product Care And Handling
Do not twist the LED strip. The LED strip has to be unreeled on a horizontal surface at the time of installation. Do not unreel the spool of LED strip before installation. LED strip manual | liniLED® PCB Deco White... -
Page 9: Cutting Instructions
Top view | Make sure the cut is vertical as illustraded in the image Top view | Only cut on the dotted lines to prevent damaging the LED above. strip. Dispose of the unnecessary material through waste recycling of electrical and electronic equipment. LED strip manual | liniLED® PCB Deco White... -
Page 10: Solder
Solder the wires to the PCB. We advise to use a cable with an area not Pre-solder the connector pads. 350o C bigger then 0.5 mm2. Pre-solder the wires. 350o C Solder the wires to the connector pads. 350o C LED strip manual | liniLED® PCB Deco White... -
Page 11: Connect Ip20
Connect IP20 Open the PCB connector. Push the liniLED® PCB LED strip into the connector. Make sure the + is above. Close the PCB connector. LED strip manual | liniLED® PCB Deco White... -
Page 12: Power Supply
Cable X liniLED® Cable 1 m Control Connect the LED strip as indicated in the figure above. The wires should be connected as follows: Red (+) and Black (-). Insert the power plug. LED strip manual | liniLED® PCB Deco White... - Page 13 Disclaimer The published information is checked to be as accurate as possible, however Triolight B.V. or any reseller of liniLED® cannot be held liable for any damages resulting from errors or outdated information. Triolight B.V. reserves the right to modify the information without informing the customers. When this document is printed or downloaded, please check for the latest version on the internet, the most up to date information will be published on www.liniLED.com.
- Page 16 Triolight B.V. Subject to misprints, errors and modifications. No legal rights can be derived from this document. V230119...
