(4) Phase signal output（P.O）
① Output current
● In case of the excitation home position, the signal is output.
(photo-coupler ON)
② Timing chart
● P.O output timing (for 1/1 STEP)
1
CWP
CCWP
P.O
● P.O output time
1/1 STEP: once in
1/2 STEP: once in
1/4 STEP: once in
1/8 STEP: once in
1/16 STEP: once in
1/32 STEP: once in 128 pulses
1/64 STEP: once in 256 pulses
a. I ≦6mA, V ＜5V
C CE
b. I ≦2mA, V
C CE(sat)
V ≦30V
CEO
2 3 0
7.2°
(For a motor with the
basic angle of 1.8°)
4 pulses
8 pulses
16 pulses
32 pulses
64 pulses
≦0.6V
1 2
1/2.5 STEP: once in
1/5 STEP: once in
1/10 STEP: once in
1/20 STEP: once in
1/25 STEP: once in
1/50 STEP: once in
1/100 STEP: once in
-33-
Instructions Manual
1 0
10 pulses
20 pulses
40 pulses
80 pulses
100 pulses
200 pulses
400 pulses
ADB-2F50B
