Specifications - Digital Watchdog STAR-LIGHT PLUS DWC-V6863WTIRW User Manual

Specifications
VIDEO
Image sensor
Active pixels
Scanning system
Fr equency
Signal technology
Synchronization
Resolution
Minimum scene illumina tion
Video output
LENS
Focal length and lens type
IR distance
OPERATIONAL
Alarm output
Shutter speed
Backlight
Starlight
Wide Dynamic Range (WDR)
1/1.8" CMOS sensors
3864(H) x 2176(V)
Progressive scan
60Hz
Max 4K
Internal
2160p @ 15fps, 1440p @ 30fps,
2.1MP/1080p @ 30fps
0.09 lux (color)
0 lux (B/W)
BNC
(Universal: HD-A / HD-TVI / HD-CVI / CVBS)
3.6~10mm Vari-focal p-iris lens
100ft
-
1/30 - 1/30,000
OFF / HME / BLC / WDR
OFF, x2 - x32 (N/A at 4K)
LOW / MIDDLE / HIGH
32
