OSD Menu_Privacy (cont.)
You can hide some parts of the camera's view to protect yout privacy and sensitive data. A total
of 24 privacy masking zones are available, including 16 square zones and 8 polygon-shaped
zones.
Polygon
1
- Zone num: Select the zone number between 0~7.
- Zone disp: Select to show or hide the selected zone.
- POS0-X: Move the zone's upper left angle left and right.
- POS0-Y: Move the zone's upper left angle up and down.
- POS1-X: Move the zone's upper right angle left and right.
- POS1-Y: Move the zone's upper right angle up and down.
- POS2-X: Move the zone's lower right angle left and right.
- POS2-Y: Move the zone's lower right angle up and down.
- POS3-X: Move the zone's lower left angle left and right.
- POS3-Y: Move the zone's lower left angle up and down.
- Y level: The higher the number, the brighter the color of the zone will appear.
- CR level: The higher the number, the more red tone will be added to the zone's color.
The lower the number, the more green will be added to the zone's color.
- CB level: The higher the number, the more red tone will be added to the zone's color.
The lower the number, the more red will be added to the zone's color.
- Trans: Set the mask's transparency level from 0~3. The default value is 2.
PRIVACY
PRIV
BOX BOX
POLYGON POLYGON
RETURN
27
POLYGON
ZONE NUM 0
ZONE DISP ON
POS0-X POS0-X
POS0-Y POS0-Y
POS1-X POS1-X
POS1-Y POS1-Y
POS2-X POS2-X
POS2-Y POS2-Y
POS3-X POS3-X
POS3-Y POS3-Y
Y LEVEL Y LEVEL
CB LEVEL CB LEVEL
CR LEVEL CR LEVEL
TRANS 2
RETURN
