Digital Watchdog Star-light Plus DWC-B6883WTIR User Manual page 13

Installation - Instructions
Using the mounting template or your camera, mark and drill the necessary holes to
1
mount the bracket to a wall or ceiling.
Pull all necessary wires through and make the proper connections. See page 14.
2
Use the four (4) mounting screws to install the camera onto the mounting surface.
3
See page 15 for tilting and pan adjustment options.
NOTE : Electrical junction box and required screws sold separately.
13
