Installation - Disassemble the camera
Before installing your camera, read the following cautions.
1. The mounting surface must withstand five times the camera weight.
2. Do not let the cables get caught in improper places or the electric line cover can
be damaged. This may cause a short or fire.
3. When installing your camera, do not allow any person to approach the installation
site. If you have any valuable things under the place, move them away.
Adjusting the camera's zoom and focus
1. Remove the front cover by turning it counter-clockwise.
2. To close the front cover, turn it clockwise.
3. If needed, readjust the camera's sun-shield cover.
Front case
NOTE: If the front cover is cross-threaded or not correctly tightened, the camera housing will
not be weatherproof.
NOTE: Install the camera's moisture absorber as needed. See the installation guide included in the box.
