Home Decorators Collection 1004151455 Use And Care Manual

Home Decorators Collection 1004151455 Use And Care Manual

Chastain electric fireplace
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
QUESTIONS, PROBLEMS, MISSING PARTS? BEFORE RETURNING TO THE STORE,
8 A.M. - 7 P.M., EST, MONDAY - FRIDAY, 9 A.M. - 6 P.M., EST, SATURDAY
We appreciate the trust and confidence you have placed in Home Decorators through the purchase of this electric fireplace. We strive to
continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
USE AND CARE GUIDE
CHASTAIN ELECTRIC FIREPLACE
CALL HOME DECORATORS COLLECTION CUSTOMER SERVICE
HOMEDEPOT.COM/HOMEDECORATORS
improvement needs. Thank you for choosing Home Decorators!
1-800-986-3460
THANK YOU
1004151455/308824335/23MM90668-PG76
1004151425/308824355/23MM90668-PO98
1004151329/308824426/23MM90668-PD01
3D INTERACTIVE
INSTRUCTIONS
FOR THIS PRODUCT ARE IN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1004151455 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Home Decorators Collection 1004151455

Summary of Contents for Home Decorators Collection 1004151455

  • Page 1 3D INTERACTIVE INSTRUCTIONS FOR THIS PRODUCT ARE IN QUESTIONS, PROBLEMS, MISSING PARTS? BEFORE RETURNING TO THE STORE, CALL HOME DECORATORS COLLECTION CUSTOMER SERVICE 8 A.M. - 7 P.M., EST, MONDAY - FRIDAY, 9 A.M. - 6 P.M., EST, SATURDAY 1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS THANK YOU We appreciate the trust and confidence you have placed in Home Decorators through the purchase of this electric fireplace.

  • Page 2: Table Of Contents

    Table of Contents Maximum Load Warning ........... 2 Package Contents .............. 8 Safety Information ............. 3 Assembly ..............9 Warranty ..............5 Operation ..............25 Pre-Assembly ............. 6 FCC/IC Information ............28 Hardware Included ........... 6 Care & Cleaning ............28 Product Specifications ............

  • Page 3: Safety Information

    Safety Information Please read and understand this entire manual before attempting to assemble, operate or install the product. If you have any question regarding the product, please call customer service at 1-800-986-3460, 8 a.m.-7 p.m., EST, Monday-Friday, WARNING: Under no circumstances should this fireplace be 9 a.m.
  • Page 4 Safety Information (continued) NOTE: Use care in assembling your new fireplace. Take your time and use the hardware provided and a quality Phillips head screwdriver. Never overtighten bolts. • Do not sit on any part of the mantel. • It is recommended to work on a soft surface like a rug or to lay out a blanket to protect the furniture from getting scratched during the assembly process NOTE:...

  • Page 5: Warranty

    Warranty Warranty 1 Year Limited Warranty: The manufacturer warrants that your new Electric Fireplace is free from manufacturing and material defects for a period of one year from date of purchase, subject to the following conditions and limitations. Install and operate this appliance in accordance with the installation and operating instructions furnished with the product at all times.

  • Page 6: Pre-Assembly

    Pre-Assembly HARDWARE INCLUDED Part Description Part Number Quantity Wood Dowel PH-DWLNTL001 Cam Lock Screw PH-KDBZNC002 Cam Lock Connector PH-KDCZNC001 Shelf Pin PH-SPNPCSPLB2 Handle with Screws Handle with Screws Screw- 3 x 12 mm PH-SCRBLK007 Screw- 4 x 16 mm PH-SCRBLK019 Slider PH-BDGBLK001 Screw- 4 x 50 mm...

  • Page 7: Product Specifications

    Pre-Assembly (continued) PRODUCT SPECIFICATIONS VOLTAGE 120VAC, 60 Hz AMPS 12.5 Amps WATTS 1500 Watts PLANNING ASSEMBLY Before beginning assembly of product, make sure all parts are present. Compare parts with Hardware Included and Package Contents lists. If any part is missing or damaged, do not attempt to assemble, install or operate the product. Contact customer service for replacement parts.

  • Page 8: Package Contents

    Pre-Assembly (continued) PACKAGE CONTENTS NOTE: All panels are labeled left and right as viewed from the front of unit. Part Description Quantity Bottom Shelf Right Surround Rail Left Door Right Door Left Partition Right Partition Top Panel Center Shelf Left Side Panel Right Side Panel Top Front Rail Upper Back Panel...

  • Page 9: Assembly

    Assembly Preparing the decorative front panels Locate the Left Surround Rail (Q) and Right Surround Rail (B) and place on a flat surface. Insert Cam Lock Screws (BB) into the pre-drilled holes on both panels as shown. Preparing the center panels Place the Left Partition (E) and Right Partition (F) on a flat surface.
  • Page 10 Assembly (continued) Attaching the door catch Locate the Left Partition (E) and the Right Partition (F) and place on a flat surface. Locate the Magnetic Door Catches (OO) and secure them to each partition using Screws (SS) where indicated by the diagram. Locate the Door Bumpers (TT) and secure one to each partition using the Screws (SS).
  • Page 11 Assembly (continued) Preparing the center shelf Locate the Center Shelf (H). Insert Wood Dowels (AA) into the pre-drilled holes along the edges of the Center Shelf (H). Preparing the center shelf Locate the Top Surround Rail (R). Insert Cam Lock Screws (BB) into the pre-drilled holes in the Top Surround Rail (R) and tighten using a Phillips screwdriver.
  • Page 12 Assembly (continued) Preparing the center assembly Using the Left Partition assembly (E) and the Center Shelf assembly (H), align the previously installed dowels and cam lock screws into the holes. Secure by inserting Cam Lock Connectors (CC) into the pre-drilled holes as shown. Use a Phillips screwdriver to tighten all Cam Lock Connectors (CC).
  • Page 13 Assembly (continued) Preparing the back base panel Connecting the base panels Insert Wood Dowels (AA) into the pre-drilled Align the Base Right Side Rail (U) with the Base Back Rail holes along the edges of the Base Back Rail (S) (S) and push together.
  • Page 14 Assembly (continued) Attaching the decorative base panel Insert Bolts (XX) through the Flat Washers (JJ) to secure the Decorative Base Panel (W). Tighten using a Phillips screwdriver. Attaching the base Preparing the side panels Locate the Left Side Panel (I) and the Right Side Align the Bottom Shelf (A) with the center assembly.
  • Page 15 Assembly (continued) Securing the side panels Align the Left Side Panel (I) with the main assembly and secure together using Screws (II) and a Phillips screwdriver. Repeat to attach the Right Side Panel (J). Securing the surround bracket Find the pre-attached Metal Plate (BBB) behind the surround and rotate it onto the back of the center shelf to span the joint.
  • Page 16 Assembly (continued) Preparing the top apron Locate the Top Front Rail (K) and place it on a flat surface. Insert the Screws (GG) through the Plastic Connector Blocks (UU) on each side of the Top Front Rail (K) as shown. Installing the top apron Align the Top Front Rail (K) with the main assembly and slide it down onto the pre-installed wood dowels.
  • Page 17 Assembly (continued) Preparing the top of the assembly Insert Wood Dowels (AA) into the pre-drilled holes in the top edges of the main assembly. Preparing the top panel for assembly Locate the Top Panel (G) and place onto a flat surface.
  • Page 18 Assembly (continued) Attaching the rolling door hanger Attaching the handles Locate the Left and Right Rolling Doors (O,P). Remove the pre-assembled screws from the Handles Place the Rolling Door Hangers (KK) on the outside of (EE), then attach to the Left Roller Door (O). the Left Roller Door (O).
  • Page 19 Assembly (continued) Attaching the door stopper Insert the Bolts (MM) through the roller track to secure the Door Stoppers (LL). Place the Door Bumpers (YY) on the inner edge of each door as indicated. Simply pull off the adhesive and stick. Attaching the track guide Insert Screws (GG) through the Sliders (HH) and into the pre-drilled holes into each Roller Door (O, P).
  • Page 20 Assembly (continued) Installing the back panels Attach the Upper Back Panel (L) and Side Back Panels (M) by inserting the Screws (FF) through the pre-drilled holes in the Upper Back Panel (L) and the Side Back Panels (M). Tighten using a Phillips Screwdriver. Attaching the adjustable shelves Insert the Shelf Pins (DD) into the pre-drilled holes on the inside of each side cabinet panel as shown.
  • Page 21 Assembly (continued) Attaching the cabinet doors Insert the Right and Left Pin Hinges (PP, QQ). Slide the Left Door (C) into the grooves. Insert Screws (RR) to secure the Left Door (C) into place. Repeat to attach the Right Door (D). Preparing the insert brackets Remove the Insert Mounting Brackets (AAA) located on the inside of the surround by...
  • Page 22 Assembly (continued) Installing the fireplace insert into the mantel assembly Lift the Fireplace Insert (X) carefully into the back of the unit and center in the fireplace insert opening. Do not drag the fireplace insert across the base as it may scratch your unit. Securing the fireplace insert Align the Insert Mounting Brackets (AAA) from step 34 and secure with the mounting screws.
  • Page 23 Assembly (continued) Adjusting the levelers The pre-attached Levelers (ZZ) are located under the base of the media unit. To level your assembled media unit, turn the Levelers as needed. HOMEDEPOT.COM/HOMEDECORATORS Please contact 1-800-986-3460 for further assistance.
  • Page 24 Assembly (continued) Installing the tipping restraint hardware When the Tipping Restraint Hardware (NN) is properly installed, it can provide protection against unexpected tipping of the Unit due to small tremors, bumps or climbing. Each Tipping Restraint Hardware (NN) includes one Unit Anchor, one Wall Anchor, one Anchor Tether, and four Anchor Screws.

  • Page 25: Operation

    Operation Operation NOTE: The control panel can be accessed at the upper-right corner of the insert. Powering the fireplace Adjusting the flame Push the Power button to supply power to all There are 6 brightness levels that can be selected: functions of the fireplace and put the insert in a standby mode.
  • Page 26 Operation (continued) Replacing the remote control battery Disposing of used batteries The battery may contain hazardous substances that When the remote control stops operating or its range could endanger the environment and human health. seems reduced, it is time to replace the batteries with new ones.
  • Page 27 Operation (continued) Patent pending Safer Plug® information SAFER PLUG This product is equipped with a Safer Plug®, which is an advanced safety device that helps detect electrical fires caused from faulty outlets. Overloading of outlets, adapters and surge protectors may cause overheating, damage, and increased risk of fires.

  • Page 28: Fcc/Ic Information

    FCC/IC Information WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for Class B digital device, pursuant to part 15 of the FCC Rules.

  • Page 29: Troubleshooting

    Troubleshooting PROBLEM ROOT CAUSE CORRECTIVE ACTION Unplug the fireplace, remove the back panel of the fireplace and check that the The thermostat sensor is thermostat is plugged into the main circuit Display shows " " broken or disconnected. board. If this does not solve the problem contact customer service for a replacement thermostat sensor.
  • Page 30 Troubleshooting (continued) PROBLEM ROOT CAUSE CORRECTIVE ACTION Flame effect works but heater With the power on press and hold the POWER function does not and the emberbed button on the control panel for 10 seconds. The heater is disabled. flashes when the Heater button is Once re-enabled the emberbed lights will pressed.

  • Page 31: Replacement Parts

    Replacement Parts For replacement parts, call our customer service department at 1-800-986-3460, 8 a.m.-7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday. Part Description Qty. Remote Control Flame Circuit Board Blue LED Circuit Board Flame Generator Drive Motor Thermostat Sensor Blower / Heater Assembly Control Panel Circuit Board...
  • Page 32 Questions, problems, missing parts? Before returning to the store call Home Decorators Customer Service 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-800-986-3460 HOMEDEPOT.COM/HOMEDECORATORS RETAIN THIS MANUAL FOR FUTURE USE.
