4. Transportation and Storage

!
Warning
(1) Handle the product with care.
(2) Do not expose to rain.
(3) The product is packed in a vinyl bag for shipment to prevent from dust. Avoid taking out of
the bag just before piping even after unpacking.
(4) If the product is kept unpacking for a certain period, select a place where there is no
moisture nor corrosive gas.
While the product shipped has been applied specified paint and surface treatment, take
care that inappropriate storing environment may cause generating rust.

5. Mounting and Piping

!
Warning
Precaution for mounting
(1) Ensure to use a filter for IN line (IN) and signal pressure line (SIG).
(2) Connect the lock-up valve after flushing piping used.
(3) The setting pressure increases when the setting screw is turned clockwise and it decreases
when the screw is turned counterclockwise.
(4) Fix by the lock nut when the setting pressure is settled.
(5) Connect piping not to leak air from piping joints.
Precaution for piping
Thoroughly flush piping to prevent entering foreign matter such as chips, cutting oil and dust before
connecting piping.
