CHARGER TECHNICAL SPECIFICATIONS
AC Input
DC Output
Charger Type
Start Voltage
Housing Protection IP20
Battery Type
Battery Capacity
Accessories
Included
Ambient
Temperature

DISPLAY MESSAGES

Startup – Display screen and all LEDs illuminate for 0.5 second.
"SMARTECH" text will scroll across the display twice followed by
"NO CONNECT" text (if nothing is connected to the charger).
TESTING is shown on digital screen, battery voltage shows (meanwhile
battery VOLTAGE LED is lit).
WBC-200
120VAC, 60Hz, 9.8A Maximum continuous, 48A
MAXIMUM INTERMITTENT.
Charge: 6/12VDC, 2A-120 Seconds,
6A-60 Seconds
Boost: 6/12VDC, 40A Continuous
Engine Start: 12VDC, 200A Intermittent 5 Seconds
On, 240 Seconds Off.
Temperature Controlled
4 step, Fully automatic charging cycle
> 1V
All Types of 6V and 12V Lead-acid Batteries
4-450Ah (6V/12V) Maintains all battery sizes
Clamp Connectors
32˚F – 104˚F (0˚C – 40˚C)
USER'S MANUAL PAGE 9
