1. DISPLAY BUTTON
2. Voltage LED indicator
3. Battery % LED indicator
4. Alternator % LED indicator
5. CHARGED/MAINTAINING LED
indicator
6. CHARGING LED indicator
7. REVERSE CONNECTION LED
indicator
8. RATE SELECTION BUTTON
9. 40A BOOST LED indicator
10. 6<>2A CHARGE/MAINTAIN
LED indicator
11. 12V 200A LED indicator
12. 12V AGM LED indicator
13. 12V GEL LED indicator
14. 6V/12V STD LED indicator
WBC-200
15. BATTERY TYPE BUTTON
16. Digital display
17. ENGINE START BUTTON
18. Handle
19. Function display panel
20. Metal bars
21. Cable base
22. Battery clamp
23. DC Power cord
24. Line cord
25. The pedestal of a charger
26. Wheel
27. Metal axis of the wheel
28. AC Power cord
USER'S MANUAL PAGE 7
