DISPLAY BUTTON
Digital display
Battery-voltage
Battery - %
Alternator - %
WBC-200
LED indicator
Voltage LED lit
Battery % LED
lit
Alternator %
LED lit
Description
When the charger is NOT charging
a battery, the display will show the
battery VOLTAGE (Voltage value /
Alternator% value / OFF in turn by
pressing DISPLAY button). When
charging BATT-06V or BATT-12V
is shown by pressing DISPLAY
button.
When in charging, the digital
display shows an estimated charge
percentage of the battery con-
nected to the charger's battery
clamps. If battery voltage is too low,
the display will show LO instead of
percentage.
The digital display shows an
estimated output percentage of
the vehicle's charging system
connected to the charger's battery
clamps, compared to a properly
functioning system. The alternator
percent range is from 0% to 100%.
Readings below 0% (13.2 volts) will
read LO and readings above 100%
(14.6 volts) will read HI. If you get a
HI or LO reading, have the
electrical system checked by a
qualified technician.
USER'S MANUAL PAGE 10
