40A BOOST (press RATE SELECTION button twice to enter based on OFF
mode) – This setting can be used for a quick boost, prior to using the engine
start setting. When Boost mode ends, VOLTAGE LED will
illuminate and display screen will show battery voltage, and meanwhile
BOOST LED will flash. Boost does NOT make battery fully charged. You
can select CHARGE/MAINTAIN mode by pressing RATE SELECTION but-
ton to continue to charge the battery

ENGINE START BUTTON

12V 200A (press RATE SELECTION button three times to enter based on
OFF mode) – Provides additional amps for cranking an engine with a weak
or run-down battery. WARNING: Always use in combination with a battery
for ENGINE START mode. Must NOT touch or disconnect clamps when
ENGINE START mode works, otherwise there may be serious injuries to
people or property.
NOTE:
1. When entering CHARGE/MAINTAIN or BOOST, the charger will
automatically detect 6V or 12V in ten seconds (display shows ON, then
ANALYSING-1). After BATT-06V or BATT-12V is showed on digital
screen, CHARGING will show (charging has started).
2. If RATE SELECTION button is not pressed in the starting 10 minutes,
the charger will automatically begin charging with 6V/12V STD and
6<>2A CHARGE/MAINTAIN if a battery is connected.

ERROR SITUATIONS

Digital display
REVERSED
NO-CONNECT
WBC-200
Warning LED
indicator
REVERSE
CONNECTION
LED lit
/
Explanation
The connections are reversed.
No battery connected / battery volt-
age is lower than 1 volt (dead battery)
/ red and black clamps are connected
together.
USER'S MANUAL PAGE 12
