Smartech WBC-200 Operator's Manual page 13

OVER-TEMP
BAD-BATT
BATTERY CHARGING TIMES
Ah - Ampere Hours
RC - Reserve Capacity
Use the following table to determine the time it will take to bring a battery to
full charge.
BATTERY SIZE/RATING(6V/12V)
SMALL BATTERIES
Motorcycle, garden tractor, etc.
CARS/
TRUCKS
WBC-200
/
/
CCA - Cold Cranking Amps
MO - Maintain Only
200-315 CCA
315-550 CCA
550-1000 CCA
Output current reduces to 0 when
temperature in charger is too high.
(exceeds 269.6˚/132˚). After cooling
down for a few minutes, the charger
will automatically begin charging with
6<>2A CHARGE/MAINTAIN rate if a
battery is connected, and the battery
type has memory
function and is the same as before.
The battery cannot store electric
charge (dead battery) after 3-minute
analysis (ANALYSING-2 Display).
6-12 Ah
12-32 Ah
40-60 RC
60-85 RC
85-190 RC
CHARGE
RATE/TIME
6A<>2A
1½ - 2½ h
2½ - 7½ h
7½ - 9½ h
9½ - 13½ h
MO
USER'S MANUAL PAGE 13
