Delfield Meridian MFPT2R-G Specifications

MERIDIAN SERIES
Glass Door Pass-Through Freezers
MODELS:
 MFPT2R-G Single section
Full height doors
Remote only
 MFPT2R-GH
Single section
Full height doors
Remote only
MFPT2R-GH
SPECIFICATIONS
Exterior: Cabinet front and shroud shall be 22-gauge
stainless steel. Exterior sides shall be aluminum. Facing
of shroud shall be easily removable without the use of
tools.
Cabinet interior shall be anodized aluminum. Bottom
& top of liner shall be die-stamped to provide
radius corners and a recessed bottom. Base shall be
fully insulated with high-density foamed in place
polyurethane.
Interior shall have three epoxy-coated wire shelves per
door section. Shelf support pilasters shall be heavy-duty
with shelves adjustable at 1.0" (2.5 cm) increments.
Units are mounted on 6" (15.24 cm) metal legs.
Doors: Unit is provided with hinged glass front door(s).
Doors on freezer units are constructed with double-pane
low-E, Argon filled tempered themopane glass. Glass
doors are constructed with a combination of extruded
aluminum & PVC, and are provided with magnetic
®
STANDARD FEATURES
• Shroud removes without tools, for easy condenser
maintenance
• Built in door locks
• Durable stainless steel doors and shroud, for lasting good
looks
• New high-density foam insulation cuts energy costs
• Big, easy grip handles are easy to find, don't intrude into
kitchen traffic
• Attractive aluminum side panels are easy to clean and
corrosion resistant
• Heavy-duty hinges with stay open feature
• Refrigeration system is located outside the food zone, more
space for product storage
• Mini watt door heaters eliminate condensation with
minimal energy cost
• Easy to read dial thermometer
• Tri seal door gaskets lower energy costs with a unique
insulating design
• Epoxy coated shelves—corrosion resistant, 300-lb.
capacity. Flexible placement on 1" centers allows
maximum storage
gaskets. Doors will have self-closing hinges and continuous
handle along vertical dimension of door(s). Glass door
constructed to eliminate need for heater wires.
• Please specify right or left hand hinging at time of order
Mechanical controls shall be located behind a removable
shroud facing.
Freezers: Refrigeration system shall use R404A
refrigerant. System shall be completely outside food zone
to maximize internal storage space. System shall utilize a
dual diversion high flow air distribution system, and shall be
a high capacity design. Evaporator coils shall have deep-
corrugated, staged fin construction for maximum efficiency
with fewer defrost cycles. Cabinet shall maintain 0
temperature.
980 S. Isabella Road
Mt. Pleasant, MI 48858
www.delfield.com
Project __________________________
Item ____________________________
Quantity _________________________
CSI Section 11400
• Aluminum interior stands up to food acids without
corroding
• Lots of interior storage space for the money
• Rugged metal legs, adjustable to compensate for
uneven floors
OPTIONS AND ACCESSORIES
 Stainless steel exterior sides
 Stainless steel interior
 Stainless steel kick plate
 Door and end laminate
 Stainless steel exterior back
 Digital thermometer
 TXV
 Chrome Shelves
 Tray Slides
 220/50/1 electrical
 Electronic control
 Stainless steel legs
 Casters
Single Voltage Models Only: Electrical connections
shall be 115 volt, 60 hertz, single phase, with an
eight ft. (2.4m) long electrical cord & plug as shown
on reference chart. Cord & plug shall be wired to the
junction box on top of the unit.
Dual Voltage Models Only: Electrical connections
shall be 115/208-230 volt, 60 hertz, single phase, and
must be hard-wired to the junction box located on top
of the unit.
F internal
0
Approval _________________
Phone: 800-733-8948
Fax: 800-669-0619
Date____________________
Email: info@delfield.com
