Solid door shallow reach-in freezers meridian series
Hide thumbs Also See for Meridian MFR1S-S:

Advertisement

Quick Links

MERIDIAN SERIES
Solid Door Shallow Reach-In Freezers
MODELS:
 MFR1S-S_
Single_section_
_
Full_height_door_
 MFR1SR-S_
Remote_
 MFR1S-SH_
Single_section_
_
Half_height_door_
 MFR1SR-SH_
Remote_
MFR1S-S
SPECIFICATIONS
Exterior: Cabinet_front_and_shroud_shall_be_22-gauge_
stainless_steel.___Exterior_sides_shall_be_made_of_
aluminum.__Facing_of_shroud_shall_be_easily_removable_
without_the_use_of_tools.
Cabinet_interior_shall_be_anodized_aluminum._Bottom_
&_top_of_liner_shall_be_die-stamped_to_provide_
radius_corners_and_a_recessed_bottom._Base_shall_be_
fully_insulated_with_high-density_foamed_in_place_
polyurethane.
Interior_shall_have_three_epoxy-coated_wire_shelves_per_
door_section._Shelf_support_pilasters_shall_be_heavy-duty_
with_shelves_adjustable_at_1.0"_(2.5_cm)_increments._
Unit_will_be_mounted_on_6"_(15.24_cm)_metal_legs.
Doors: Solid_doors_shall_have_a_22-gauge_stainless_
steel_exterior_&_anodized_aluminum_interior_liner._
Doors_shall_be_fully_insulated_with_high_density_foamed_
in_place_polyurethane._Each_door_shall_have_two_
®
 MFR2S-S_
_
 MFR2SR-S_
 MFR2S-SH_
_
 MFR2SR-SH_
STANDARD FEATURES
•_ Shroud_removes_without_tools,_for_easy_condenser_
maintenance
•_ Built_in_door_locks
•_ Durable_stainless_steel_doors_and_shroud,_for_lasting_good_
looks
•_ New_high-density_foam_insulation_cuts_energy_costs
•_ Big,_easy_grip_handles_are_easy_to_find,_don't_intrude_into_
kitchen_traffic
•_ Attractive_aluminum_side_panels_are_easy_to_clean_and_
corrosion_resistant
•_ Heavy-duty_hinges_with_stay_open_feature
•_ Refrigeration_system_is_located_outside_the_food_zone,_more_
space_for_product_storage
•_ Mini_watt_door_heaters_eliminate_condensation_with_minimal_
energy_cost
•_ Exterior_digital_thermometer_with_high/low_temperature_
alarm
•_ Tri_seal_door_gaskets_lower_energy_costs_with_a_unique_
insulating_design
•_ Epoxy_coated_shelves—corrosion_resistant,_300-lb._capacity.__
Flexible_placement_on_1"_centers_allows_maximum_storage
self-closing,_cam-lift_style_hinges._Doors_shall_be_easily_
removable_without_use_of_tools._Door_gaskets_shall_be_
magnetic_snap-in_style_to_allow_simple_replacement._
Door_handles_shall_be_recessed.
•_Please_specify_right_or_left_hand_hinging_at_time_of_
order.
Mechanical_controls_shall_be_located_behind_a_removable_
shroud_facing._
Freezers: All_components_are_mounted_to_the_
exterior_cabinet_ceiling,_outside_the_food_zone_and_are_
assembled_as_one_piece_and_can_be_removed_as_one_
piece.__Environmentally_friendly_R404A_refrigerant_is_
used.__System_has_the_capability_of_maintaining_between_
-5˚F_and_0˚F_in_heavy_use_food_service_operations.__
Refrigerant_is_metered_using_a_highly_responsive_
thermostatic_expansion_valve.__Evaporator_defrost_is_
980_S._Isabella_Road
Mt._Pleasant,_MI_48858
www.delfield.com
Project_ __________________________
Item_____________________________
Quantity_ _________________________
CSI_Section_11400
Two_section_
Full_height_doors
Remote
Two_section
Half_height_doors
Remote
•_ Aluminum_interior_stands_up_to_food_acids_without_
corroding
•_ Lots_of_interior_storage_space_for_the_money
•_ Rugged_metal_legs,_adjustable_to_compensate_for_
uneven_floors
OPTIONS AND ACCESSORIES
 Stainless_steel_exterior_sides
 Stainless_steel_interior
 Stainless_steel_kick_plate
 Door_and_end_laminate
 Stainless_steel_exterior_back
 Digital_thermometer
 TXV
 Chrome_Shelves
 Tray_Slides
 220/50/1_electrical
 Electronic_control
 Stainless_steel_legs
 Casters
automatic_using_a_time_initiated,_time/temperature_
terminated_system_with_electric_heaters.__Evaporator_
condensate_is_eliminated_using_an_energy_efficient_hot_
gas_system.
Single Voltage Models: Electrical_connections_
shall_be_115_volt,_60_hertz,_single_phase,_with_an_
eight_ft._(2.4m)_long_electrical_cord_&_plug_as_shown_
on_reference_chart._Cord_&_plug_shall_be_wired_to_the_
junction_box_on_top_of_the_unit.
Dual Voltage Models Only: Electrical_connections_
shall_be_115/208-230_volt,_60_hertz,_single_phase,_
and_must_be_hard-wired_to_the_junction_box_located_on_
top_of_the_unit.
Approval__________________
Phone:_800-733-8948
Fax:_800-669-0619
Date_ _ ___________________
Email:_info@delfield.com
