Introducing the USB-7204

The USB-7204 is a USB 2.0 full-speed device that is supported under the following operating systems:

Microsoft Windows 7/Vista/XP (32-bit or 64-bit)

Microsoft Windows CE

Macintosh (32-bit or 64-bit)

Linux (32-bit or 64-bit)
The USB-7204 is compatible with both USB 1.1 and USB 2.0 ports.
The device that provides the following features:

8 channels of 16-bit analog input
Configurable for eight 11-bit single-ended inputs (represented as 12-bit data — even values only) or
o
four 12-bit differential inputs.

Two 12-bit analog outputs

16 individually configurable digital I/O channels

32-bit event counter

Digital trigger input

Bidirectional SYNC pin for external clocking and synchronization with another board
The device is powered by the +5 volt USB supply from your computer, and requires no external power.
