- Page 1 BERTAZZONI INSTALLATION MANUAL & USER GAS COOKTOP 3100534 WWW.BERTAZZONI.COM...
-
Page 2: Table Of Contents
__________________________________________________ GAS CONVERSION _____________________________________________________________ INSTALLATION CHECKLIST ______________________________________________________ FINAL PREPARATION ___________________________________________________________ BERTAZZONI SERVICE _________________________________________________________ USER _______________________________________________________________________ WARNINGS ____________________________________________________________________ WORKTOP AND KNOBS LAYOUT _________________________________________________ GAS COOKTOP ________________________________________________________________ ELECTRIC GRIDDLE ____________________________________________________________ KEEPING YOUR BERTAZZONI CLEAN _____________________________________________ TROUBLESHOOTING ___________________________________________________________ TWO YEARS LIMITED WARRANTY ________________________________________________... - Page 3 / Models Models Models PROF244CTXV PROF305CTXV PROF365CTXV...
-
Page 4: Warnings
/ Warnings WARNINGS To ensure proper and safe operation, the applian- WARNING! ce must be properly installed and grounded by a If the information in these instructions is qualifi ed technician. DO NOT attempt to adjust, not followed exactly, a fi re or explosion may repair, service, or replace any part of your ap- result causing property damage, personal pliance unless it is specifi... - Page 5 / Warnings WARNING: Cancer and Reproductiv Harm- www.P65Warnings.ca.gov...
-
Page 6: Data Rating Label
/ Data rating label / Before installation DATA RATING LABEL The data rating label shows the model and serial A manual valve shall be installed in an accessible number of the cooktop. It is located under the ran- location in the gas line external to the appliance getop and in the last page of this manual. -
Page 7: Ventilation Preparation
SPECIFICATIONS 2” 3/8 (6,1 cm) 3/8 (1cm) 18” 11/16 (47,4 cm) 1” 1/2 (3,8 cm) PROF244CTXV 23” 3/16 (60,5 cm) 20” 5/8 (52,5 cm) 2” 5/8 (6,6 cm) 6” (15,3 cm) PROF305CTXV 27” 3/4 (75,5 cm) 20” 5/8 (52,5 cm) 2”... - Page 8 / Specifi cations Min Rate By-pass Pressure Pressure Max Rate Max Rate Min Rate By-pass Burner Burner Injector Injector [iwc] [Btu/hr] [Btu/hr] diam.[mm] diam.[mm] Type 4’’ 3,750 1,098 Regulated Auxiliary 0.92 10’’ 3,750 1,098 0.29 0.56 LP (Propane) 4’’ 6,000 1,729 1,500 Regulated...
-
Page 9: Clearence Dimensions
ANSI Z21.1 scope and are not certifi ed by CSA. Clearances of less than 12” (305 mm) must be approved by the local codes and/or by the local authority having jurisdiction. PROF244CTXV PROF305CTXV PROF365CTXV 18” 7/8 (48cm) 18” 7/8 (48cm) 18”... - Page 10 / Clearence dimensions TECHNICAL INSTALLATION INSTRUCTIONS INSTALLING THE HOB ABOVE A CUPBOARD INSTALLING THE HOB ABOVE AN OVEN The clearance between the hob and the OR DRAWERS The clearance between the hob and the kitchen furniture or other installed appliances kitchen units must be enough to ensure must be enough to ensure suffi...
- Page 11 / Clearence dimensions HOB FASTENING In order to prevent accidental water ingress into the unit below, the appliance is fi tted with a special gasket. 1) remove the grids, burners and burners caps 2) Turn the hob upside down over a soft surface. 3) Lay the sealing gasket out along the lower edge of the built-in hob after cleaning the mating surface.
-
Page 12: Installation Requirements
/ Installation requirements / Electrical connection INSTALLATION REQUIREMENTS ELECTRICAL CONNECTION Warning! ELECTRICAL ELECTRICAL SHOCK HAZARD A properly-grounded horizontally- mounted electri- Disconnect electrical power at the circuit bre- cal receptacle should be installed. aker box or fuse box before installing the ap- Check all local code requirements. -
Page 13: Wiring Diagram
/ Wiring diagram WIRING DIAGRAM The electric wiring diagrams and schematics are attached behind the rangetop, and should not be removed except by a service technician, then replaced after service. -
Page 14: Gas Connection
/ Gas connection GAS CONNECTION Warning! FLEXIBLE CONNECTIONS DO NOT USE AN OPEN FLAME WHEN In case of installation with fl exible couplings and/ CHECKING FOR LEAKS! or quick-disconnect fi ttings, the installer must use a heavy-duty, AGA design-certifi ed commercial fl... -
Page 15: Pressure Regulator
/ Gas connection PRESSURE REGULATOR Since service pressure may fl uctuate with local demand, every gas cooking appliance must be equipped with a pressure regulator on the inco- ming service line for safe and effi cient operation. The pressure regulator shipped with the applian- ce has two female threads ½”... -
Page 16: Installation
/ Installation INSTALLATION APPLIANCE INSTALLATION Unpacking the rangetop • Remove all packing materials from the shipping pallet but leave the adhesive-backed foam layer over brushed-metal surfaces to protect it from scratches until the range is installed in its fi nalposition. Only the fi lm on the side panels should be removed before inserting the range between the cabinets. -
Page 17: Gas Conversion
Save the nozzles removed from the rangetop for Replace nozzles using the conversion set sup- future use. plied with the rcooktop or by a Bertazzoni authori- zed parts warehouse. Each nozzle has a number Step 1: pressure regulator indicating its fl ow diameter printed on the body. - Page 18 / Gas conversion Step 4: minimum fl ame adjustment WARNING! These adjustments should be made only for use of the appliance with natural gas. For use with li- quid propane gas, the choke screw must be fully turned in a clockwise direction. SURFACE BURNERS Light one burner at a time and set the knob to the MINIMUM position (small fl...
-
Page 19: Installation Checklist
/ Installation checklist / fi nal preparation INSTALLATION CHECKLIST FINAL PREPARATION A qualifi ed installer should carry out the following • Before using the cooktop, remove any checks: protective wrap from the stainless steel. • All stainless steel body parts should be wiped with hot, soapy water and with a liquid stainless Island trim or Backguard attached accor- steel cleanser. -
Page 20: Bertazzoni Service
We have a dedicated team of trained professionals to answer your ne- eds. If you own a Bertazzoni appliance and need ser- vice in the US or Canada please use the following contact information: e-mail: aftersaleservice@bertazzoni.com Telephone - Monday through Friday, 7.30am to 7.30pm EST (except US public holidays). -
Page 21: User
/User manual BERTAZZONI USER MANUAL GAS COOKTOP... -
Page 22: Warnings
/User Wrarning WARNINGS Warning and Important Safety Instructions ap- of the gas shut-off valve and how to shut it off in pearing in this manual are not meant to cover all an emergency. possible conditions and situations that may occur. Common sense, caution, and care must be exer- A certifi... - Page 23 / Warnings • Have the installer show you where the gas Cooking Safety shut-off valve is located. • Once the unit has been installed as outlined • For proper burner performance, keep igniters in the Installation Instructions, it is important clean and dry.
-
Page 24: Worktop And Knobs Layout
/ Worktop and knobs layout WARNINGS WORKTOP AND KNOBS LAYOUT Cleaning Safety CONTROLS / BURNERS • Turn off all controls and wait for appliance parts 1 Front right auxiliary burner to cool before touching or cleaning them. DO 2 Rear right semi-rapid burner NOT touch the burner grates or surrounding 3 Rear left semi-rapid burner areas until they have had suffi... -
Page 25: Gas Cooktop
/ Bertazzoni service GAS COOKTOP BURNER CAPS AND GRATES The correct fl ame height depends on: • size and material of pan being used The burners and the burner caps must be proper- • food being cooked ly placed for the cooktop to function properly. - Page 26 / Gas cooktop USING THE POWER BURNER GAS SHUT-OFF SAFETY - To give further fl exibility, the dual power burner THERMOCOUPLE can be used as a single simmer burner if the cen- tral burner alone is ignited or as a power burner if A fl...
-
Page 27: Keeping Your Bertazzoni Clean
/ Keeping your Bertazzoni clean KEEPING YOUR BERTAZZONI CLEAN Burn hazard Make sure the heating elements are turned off and allowed to cool completely before any clea- ning and/or maintenance operation. Things to avoid: • Do not use a steam cleaner to clean the rangetop: the steam could reach electrical components and cause a short. -
Page 28: Troubleshooting
Here are answer to common problems you may experience. You are also welcome to call our toll free Customer Service line to trouble- shoot any issue with your Bertazzoni: ENGLISH 866 905 0010 if located in the US, BC, B, Sk and MB... -
Page 29: Two Years Limited Warranty
Defects and damage arising from external forces porcelain, with the exclusion of slight diff erences beyond the control of Bertazzoni SpA such as fi re, in color due to materials and painting/enamelling fl ood, earthquakes and other acts of God. - Page 30 ...
- Page 31 ...
