- Page 1 1550 Series In-Row Ripper Operator’s Manual LANDOLL CORPORATION 1900 North Street Marysville, Kansas 66508 (785) 562-5381 800-428-5655 ~ WWW.LANDOLL.COM F-298-0111 01/2011...
-
Page 3: Table Of Contents
Table of Contents Introduction Understanding Safety Statements ..........1-2 Standard Specifications Assembly Instructions Assembly Preparation . - Page 4 F-298-0111 Edition...
-
Page 5: Introduction
Chapter 1 Introduction The Landoll Model 1550 In-Row Ripper is a quality product designed to give years of trouble free performance. By following each section of this manual, your system will perform as designed for you and your operation CHAPTER 1 gives basic instructions on the use of this manual. -
Page 6: Understanding Safety Statements
INTRODUCTION Understanding Safety Statements You will find various types of safety information on the following pages and on the machine signs (decals) attached to the vehicle. This section explains their meaning. The Safety Alert Symbol means ATTENTION! YOUR SAFETY IS INVOLVED! ... -
Page 7: Standard Specifications
Chapter 2 Standard Specifications 1550 SERIES IN-ROW RIPPER SPECIFICATIONS ESTIMATED MODEL NO. OF SHANK TRANSPORT WEIGHT SHANKS SPACING SHANK EXTENSIONS WIDTH (LBS.) 1553A30 30” NONE 8’-3” 2,271 1553A36 36” NONE 8’-3” 2,271 1553A38 38” NONE 8’-3” 2,271 1553A40 40” NONE 8’-3”... - Page 8 STANDARD SPECIFICATIONS 1550 SERIES IN-ROW RIPPER SPECIFICATIONS ESTIMATED MODEL NO. OF SHANK TRANSPORT WEIGHT SHANKS SPACING SHANK EXTENSIONS WIDTH (LBS.) 1558E38 38” 58” WING 19’-10” 5,415 1558E40 40” 58” WING 19’-5” 5,415 1559E30 30” 46” WING 20’-3” 5,663 TIRE INFLATION...
- Page 9 STANDARD SPECIFICATIONS...
- Page 10 STANDARD SPECIFICATIONS LANDOLL CORPORATION GENERAL TORQUE SPECIFICATIONS (REV. 4/97) THIS CHART PROVIDES TIGHTENING TORQUES FOR GENERAL PURPOSE APPLICATIONS WHEN SPECIAL TORQUES ARE NOT SPECIFIED ON PROCESS OR DRAWING. ASSEMBLY TORQUES APPLY TO PLATED NUTS AND CAPSCREWS ASSEMBLED WITHOUT SUPPLEMENTAL LUBRICATION (AS RECEIVED CONDITION). THEY DO NOT APPLY IF SPECIAL GRAPHITE MOLY-DISULFIDE OR OTHER EXTREME PRESSURE LUBRICANTS ARE USED.
- Page 11 STANDARD SPECIFICATIONS LANDOLL CORPORATION HYDRAULIC FITTING TORQUE SPECIFICATIONS JIC, ORS, & ORB (REV. 10/97) THIS CHART PROVIDES TIGHTENING TORQUES FOR HYDRAULIC FITTING APPLICATIONS WHEN SPECIAL TORQUES ARE NOT SPECIFIED ON PROCESS OR DRAWING. ASSEMBLY TORQUES APPLY TO PLATED CARBON STEEL AND STAINLESS STEEL FITTINGS ASSEMBLED WITHOUT SUPPLEMENTAL LUBRICATION (AS RECEIVED CONDITION) THEY DO NOT APPLY IF SPECIAL GRAPHITE MOLY-DISULFIDE OR OTHER EXTREME PRESSURE LUBRICANTS ARE USED.
- Page 12 STANDARD SPECIFICATIONS F-298-0111 Edition...
-
Page 13: Assembly Instructions
Chapter 3 Assembly Instructions It is very important that your new 1550 Series In-Row IMPORTANT Ripper be properly assembled, adjusted, and lubricated before use. Illustrations are provided in this section to Check all bolt lengths, nut sizes, etc., from the parts show proper assembly procedures. - Page 14 SMV MOUNTING BRACKET WARNING LIGHT BAR 1/2-13 X 5-1/2 HEX HEAD CAP SCREW 1/2-13 HEX LOCK NUT RIGID GAUGE WHEEL ADJUSTMENT PIN 3/16 HAIR PIN OUTER JACK STAND TUBE JACK STAND m1550-parts-id Figure 3-1: 1550 Series Parts Identification F-298-0111 Edition...
-
Page 15: Assembly Preparation
ASSEMBLY INSTRUCTIONS Assembly Preparation SMV Bracket Installation 1. Hook up the In-Row Ripper to a tractor using the 1. Install the SMV mounting bracket and light bar close three-point hitch. Raise the unit about 36” and place to the center of machine on rear frame member using stands under the main frame to prevent accidental 1/2-13 X 5-1/2 hex head cap screws and hex lock lowering. - Page 16 ASSEMBLY INSTRUCTIONS 1-8 X 8-1/2 HEX RH SPRING ANCHOR HEAD CAP SCREW PLATE DANGER COIL 1-8 HEX LOCK NUT SPRING DECAL LH SPRING ANCHOR 5/8-11 X 4 HEX PLATE HEAD CAP SCREW COIL SPRING ASSEMBLY WEAR GUARD STOP BRACKET 5/8-11 HEX LOCK NUT SHANK ASSEMBLY SPRING CLAMP WELDMENT...
-
Page 17: Parabolic Shank Assembly
ASSEMBLY INSTRUCTIONS Parabolic Shank Assembly IMPORTANT 1. The spring clamp weldments are already located on 1-8 x 8-1/2 hex head cap screw located in spring the frame at the proper spacing. anchor plates should be installed in opposite direction to 1-8 x 8-1/2 hex head cap screw in spring 2. - Page 18 ASSEMBLY INSTRUCTIONS 1-8 HEX LOCK NUT COIL SPRING ASSEMBLY SHANK BRACKET WELDMENT 1-8 X 8-1/2 HEX HEAD CAP SCREW 1-8 X 6-1/2 HEX SPRING CLAMP HEAD CAP SCREW WELDMENT PLASTIC BEARING NARROW CLAMP WELDMENT 3/4-10 HEX LOCK NUT 3/4-10 X 8-1/2 HEX NARROW SHANK HEAD CAP SCREW ROLL PIN...
-
Page 19: Straight Shank Assembly
ASSEMBLY INSTRUCTIONS Straight Shank Assembly IMPORTANT 1. The spring clamp weldments are already located on Do not overtighten bolts as the springs must be free the frame at the proper spacing. to pivot. 2. Attach shank bracket weldment to the spring clamp 4. -
Page 20: Coulter Assembly
ASSEMBLY INSTRUCTIONS FRAME SHANK 3/8 X 2 SPRING SLOTTED PIN CLAMP 1/2-13 X 6 HEX HEAD CAP SCREW 5/8-11 X 1-1/2 SET SCREW 1/2 SPLIT LOCK 1/2-13 HEX NUT WASHER CLAMP PLATE COULTER ASSEMBLY 1/2-13 X 1-1/2 ROUND HEAD SQUARE NECK SCREW 1/2 SPLIT LOCK WASHER... -
Page 21: Electrical Installation
ASSEMBLY INSTRUCTIONS #7 BLUE WIRING CHART #1 WHITE 7-PIN 4-PIN CONNECTION CONNECTION #2 BLACK #6 BROWN GRND. 1 YEL. 3 #3 YELLOW #5 GREEN GRN. 5 BRN. 6 #4 RED FACING CONNECTOR HARNESS EXTENSION 1/4-20 X 1-1/4 HEX HEAD CAP SCREW REAR WIRING HARNESS RH WARNING LIGHT 1/4-20 HEX LOCK NUT... - Page 22 ASSEMBLY INSTRUCTIONS 6 HOSE HYDRAULIC MANIFOLD O-RING PLUG 90 ELBOW W/ RESTRICTOR 1/2 MALE COUPLER 4 X 20 HYDRAULIC CYLINDER m1550-hydraulics Figure 3-6: Hydraulic Assembly - D and E Models 3-10 F-298-0111 Edition...
-
Page 23: Hydraulic Installation (D And E Models Only)
8. Install o-ring plug in rear ports of hydraulic manifold. end of the left hydraulic cylinder. 4. Install Hose 2 from hydraulic manifold to the rod end of the left hydraulic cylinder. 1550 SERIES HYDRAULIC HOSE ITEM PART NUMBER DESCRIPTION... - Page 24 ASSEMBLY INSTRUCTIONS 4 X 1/4 SQUARE TUBE U-BOLT 7/8-9 HEX LOCK NUT OPTION BAR BEDDING SHANK BRACKET BRACKET WELDMENT WELDMENT FRAME 7/8-9 X 3-1/4 HEX HEAD CAP SCREW BEDDING CLAMP PLATE BEDDING ATTACHMENT SHANK U-BOLT 3/4-10 HEX NUT 5/8-11 HEX LOCK NUT 1-8 HEX LOCK NUT 5/8-11 X 3 HEX HEAD CAP SCREW...
-
Page 25: Bedding Attachment Assembly (Option)
ASSEMBLY INSTRUCTIONS Bedding Attachment Assembly 4. Slide bedding attachment shank into bedding shank bracket weldment. Hold in place with 7/8-9 x 3-1/4 (Option) hex head cap screws and hex lock nuts. 5. Slide shank foot piece onto lower end of bedding 1. - Page 26 ASSEMBLY INSTRUCTIONS Notes: 3-14 F-298-0111 Edition...
-
Page 27: Operation And Maintenance
Chapter 4 Operation and Maintenance DANGER WARNING Coulter blades are sharp. Do not allow coulters to All hydraulically elevated equipment must be roll over or fall on any part of the body. Do not locked out or lowered to the ground when allow wrenches to slip when working near coulter servicing or when equipment is idle, to prevent blades. -
Page 28: Tractor Preparation
A & B FRAMES - CAT III HITCH m1550-hitch Figure 4-1: 3 Point Hitch Setup Tractor Preparation The 1550 Series In-Row Ripper may be used on tractors equipped with category II or III three-point hitches. Before attaching the In-Row Ripper, prepare the tractor as follows: The rear tractor tires should be inflated equally and ballast added according to the tractor operator’s manual. -
Page 29: In-Row Ripper Operation
OPERATION AND MAINTENANCE In-Row Ripper Operation Field Operation — Three-Point Hitch Type 1. Before operating the In-Row Ripper, inspect it to be sure it is in good operating condition. 1. Lower the In-Row Ripper to the ground and pull it a 2. -
Page 30: Wheel Bearing Maintenance
9. Install a new cotter pin and the hub cap. Seal kits are available from your Landoll dealer. 10. Wheel bearing maintenance should be performed at 2. Check all hydraulic hoses weekly. Look for binding or the beginning of every season of use. - Page 31 OPERATION AND MAINTENANCE Notes...
- Page 32 OPERATION AND MAINTENANCE F-298-0111 Edition...
-
Page 33: Troubleshooting Guide
Troubleshooting Guide The Troubleshooting Guide, shown below, is included to help you quickly locate problems that can happen using your 1550 Series In-Row Ripper. Follow all safety precautions stated in the previous sections when making any adjustments to your machine. - Page 34 TROUBLESHOOTING GUIDE Notes F-298-0111 Edition...
- Page 36 Equipment from Landoll Corporation is built to exacting standards ensured by ISO 9001:2008 registration at all Landoll manufacturing facilities. Model 1550 Series In-Row Ripper Operator’s Manual Re-Order Part Number F-298-0111 LANDOLL CORPORATION 1900 North Street Marysville, Kansas 66508 (785) 562-5381 800-428-5655 ~ WWW.LANDOLL.COM...
