C
ONTENTS
Standard and Industrial Versions: Installation.............................. 3
Testing the Sensor.......................................................................... 3
Installing the Sensor....................................................................... 4
Typical Standard Installation......................................................... 4
Typical Industrial Installation........................................................ 5
Mounting on the Sensor Mounting Arm......................................... 6
Mounting on the Sensor Tilting Bracket........................................ 7
Mounting on a Wood Surface.......................................................... 10
Routing Sensor Cable..................................................................... 10
Vantage Pro Version: Installation on the Sensor Mounting Shelf.. 12
Testing the Sensor.......................................................................... 12
Accessing the SIM........................................................................... 12
Securing the Sensor on the Shelf.................................................... 13
Routing Sensor Cable..................................................................... 14
If You Are Going to Install the Solar Radiation Sensor................. 15
Maintaining the Sensor.................................................................. 15
Technical Support.......................................................................... 16
S
PECIFICATIONS ARE
For detailed technical information on the UV sensor, call Technical Support
(510) 732-7814 to request a specification sheet, or download it from our website:
http://www.davisnet.com/support/weather/
S
TANDARD AND

Testing the Sensor

1. Attach the sensor cable to the connector S3 on the sensor interface module, or "SIM".
Consult the System Installation manual for instructions.
2. Press UV on the Health EnviroMonitor to make sure you are getting a UV reading.
Consult the Health EnviroMonitor manual for instructions on displaying UV.
3. Shade the sensor and make sure the reading drops.
Contents
A
VAILABLE
I V
NDUSTRIAL ERSIONS
: I
NSTALLATION
Page 3
