5. Run the power cord
from the kit up through
one of the shelter open-
ings at the bottom of the
Complete System Shel-
ter or Multi-Purpose
Shelter.
6. Plug it into the console
or Envoy's POWER
slot. The console should
beep three times within
10 seconds if the con-
sole is working prop-
erly. The Weather
Envoy should beep
twice within 10 sec-
onds if the Envoy is
working properly. The
Envoy or console
should beep three times
within 20 seconds if it is
connected to a com-
puter with WeatherLink
installed.
7. Check all of the
readings on your
display to be sure
they display cor-
rectly. Consult
your owner's man-
ual for instructions
on displaying the
various readings.
Spin the wind
cups, move the
wind vane, and tip
the rain bucket to
verify wind speed
and direction and
rainfall readings.
If the console is
receiving power
but is having prob-
lems reading the
6
Vantage Pro2
Console
Solar Power Adapter Cable
Connecting the Solar Power Cable
|to the Console
Envoy
I.S.S. Cable
Solar Power
Solar Cable
Adapter Cable
for Vantage Pro2
Connecting the Solar Power Cable
to the Weather Envoy
USB
WeatherLink
I.S.S.
Data Logger
Cable
for Vantage Pro2
Solar Cable
Multi-Purpose
Shelter
