3. Control parameters and display channels

3.1 Overview of channels

Legend:
x
Corresponding channel is available.
x*
Corresponding channel is available when the corresponding
option is enabled
Note:
Only if temperature sensors are connected, will S3 and S4
be displayed.
channel description
COL temperature collector 1
TST temperature store 1
TST temperature store
S3 temperature Sensor 3
TRF temperature return sensor
S4 temperature Sensor 4
h P operating hours relay 1
kWh heat quantity kWh
MWh heat quantity MWh
DT O switch-on temperature difference
DT F switch-off temperature differ-
ence 1
S MX maximum temperature store 1
EM emergency temperature collec-
tor 1
8
|

Only if the option heat quantity measurement is activated
(OHQM), will the corresponding channel be available.

Only if the option heat quantity measurement is deactivated
(OHQM), will the corresponding channel be available.
MEDT
Only if an antifreeze (MEDT) other than water or Tyfo-
cor LS / G-LS (MEDT 0 or 3) is used, will the channel
antifreeze concentration (MED%) be displayed.
page channel
9 OCX
9
CMX
9
9
OCN
9
CMN
9
9
OCF
10
CFR
10
OREC
10
O TC
10
OHQM
11
FMAX
11
MEDT
MED%
HND1
LANG
PROG
VERS
description
option collector cooling collector
1
maximum temperature collector 1
option minimum limitationcollec-
tor 1
minimun temperature collector 1
option antifreeze collector 1
antifreeze temperature collector 1
option recooling
pption tube collector
option heat quantity measurement
Maximum flowrate
antifreeze type
antifreeze concentration
Manual operation relay 1
language
program number
version number
page
11
11
11
11
12
12
12
12
12
12
12
12
12
12
