2/28/2019
How to configure CP Series for 3CX
This guide applies to v15.5 only.
On this topic
Supported Models: Yealink CP series
Step 1: Upgrade to the Required firmware
Step 2: Factory Reset the IP Phone
Step 3: Provision the phone
Local LAN: Provision via Plug'n'Play
Supported Models: Yealink CP series
● Yealink CP860
● Yealink CP920
● Yealink CP960
Step 1: Upgrade to the Required firmware
Ensure that the phone is running on the required firmware by 3CX. In case the device needs manual updating
download the latest distributed required firmware by 3CX here. Read how to check what firmware the phones
are running on and how to upgrade them in this guide:
Step 2: Factory Reset the IP Phone
Before provisioning the IP phone, the phone must be brought back to factory defaults in case the device has
residual settings of a previous configuration. To reset the device read our
phones
document.
Step 3: Provision the phone
There are several methods to provision a phone:
https://www.3cx.com/sip-phones/yealink-cp-series/
Auto Provision your Yealink CP series IP Phone for 3CX v15
How to manual upgrade Yealink IP
phones.
How to Factory Reset Yealink
1/5
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Yealink CP Series
Summary of Contents for Yealink CP Series
- Page 1 2/28/2019 Auto Provision your Yealink CP series IP Phone for 3CX v15 How to configure CP Series for 3CX This guide applies to v15.5 only. On this topic Supported Models: Yealink CP series Step 1: Upgrade to the Required firmware...
- Page 2 2/28/2019 Auto Provision your Yealink CP series IP Phone for 3CX v15 ● Plug & Play - For phones on the local LAN or behind the 3CX SBC. ● RPS - For phones on remote networks that will connect directly to 3CX and use STUN.
- Page 3 2/28/2019 Auto Provision your Yealink CP series IP Phone for 3CX v15 4. All major provisioning settings are pre-populated. If your PBX has multiple network cards, select to which network this IP phone is connected. 5. Click “OK”. The phone will configure automatically and will reboot to finalize the setup.
- Page 4 2/28/2019 Auto Provision your Yealink CP series IP Phone for 3CX v15 6. You can make sure that the extension is ready to be configured via RPS by checking the “Event Log” from the dashboard: If the message appears as a “Warning” follow the instructions outlined in the message and use the Manual Link Provisioning method outlined here.
- Page 5 2/28/2019 Auto Provision your Yealink CP series IP Phone for 3CX v15 Note: Ensure that the input mode is set to digits (green box). Step 4: Extended Phone Configuration IP phones can be tweaked to match the user’s needs. Those might be skipped if they are not desired and the phone will be rolled out in a default configuration.
