Directed Electronics AdvantGuard 5 Owner's Manual page 45

Read the following instructions thoroughly for a full understanding of
how to properly adjust this sensor.
1. Disarm system
2. Transmit Channel 16 (Press
1-time)
The LED will turn on and the siren will chirp 1-time.
Primary (full trigger) zone adjustment has now been
entered.
Primary zone can now be adjusted.
3. Adjusting Primary Zone
Press
Press
The sensor Primary zone can be tested at any time dur-
ing adjustment and will generate 1 siren chirp each
time the zone is activated.
4. Press
Siren chirps 1 time.
Warn-away Zone adjustment has now been entered.
Warn-away Zone can now be adjusted.
5. Adjust Warn-away Zone
Press
Press
The sensor Warn-away zone can be tested at any time
during adjustment and will generate 1 siren chirp each
time the zone is activated.
42
of the remote control to increase sensitivity.
of the remote control to decrease sensitivity.
to adjust Warn-Away zone
to increase sensitivity.
to decrease sensitivity.
3-times then
