DESCRIPTION OF THE DEVICE
PERFORM A MEASUREMENT
Turn on the de device by pressing on "On/Off/Esc".
➢
The device displays its name "LV110", "LV111" or "LV117".
Put the probe to the required location.
➢
The device displays the velocity and temperature measurement.
FREEZE THE MEASUREMENT
During a measurement:
Press once on "Hold/min/max".
➢
"Hold" appears on screen and the measurement is frozen.
Press on "On/Off/Esc" to exit the hold function.
➢
The device returns to the measurement display.
DISPLAY THE MINIMUM AND THE MAXIMUM
Once the measurement is frozen:
Press on "Hold/min/max".
➢
The device displays the maximum value of velocity or airflow measured since the last questioning at the top of the screen and the minimum
value of velocity or airflow measured since the last questioning at the bottom of the screen.
Press again on "Hold/min/max".
➢
The device displays the maximum value of temperature measured since the last questioning at the top of the screen and the minimum value of
temperature measured since the last questioning at the bottom of the screen.
Press on "On/Off/Esc" to return to the measurements display.
➢
Vane probe thermo-anemometer
LV 110 – LV 111 – LV 117
Backlight key
Select key
OK key
On/Off/Esc key
Hold/min/max key
Advertisement
Table of Contents
Related Manuals for Kimo LV 110
Summary of Contents for Kimo LV 110
- Page 1 Vane probe thermo-anemometer LV 110 – LV 111 – LV 117 DESCRIPTION OF THE DEVICE OK key Backlight key On/Off/Esc key Select key Hold/min/max key PERFORM A MEASUREMENT Turn on the de device by pressing on “On/Off/Esc”. ➢ The device displays its name “LV110”, “LV111” or “LV117”.
- Page 2 PERFORM AN AVERAGE IN VELOCITY The device is on and displays the measurement. Press on “OK”. ➢ “START” displays on screen. Press on “OK”, the average calculation is launched, “END” displays on screen, “AVG” blinks. ➢ Press on “OK” to stop the calculation, the average displays. ➢...
- Page 3 Select the measuring unit in velocity The device is on and in velocity mode. Press on “Select” until “UNIT” blinks on screen. ➢ Press on “OK”. ➢ The unit currently used blinks on screen. Press on “Select” until the required unit appears: m/s, fpm or km/h. ➢...
- Page 4 ➢ Change the old batteries by AAA LR03 1.5V batteries. ➢ Replace the front part. ➢ Once returned to KIMO, required waste collection will be assured in the respect of the environment in accordance to 2002/96/CE guidelines relating to WEEE...
