Summary of Contents for Clarke Air SP15ND
- Page 1 Air Compressor ENGINE DRIVEN Operating & Maintenance Instructions © 1110 - 1 -...
-
Page 2: Specifications
Read these safety instructions before using the equipment. INTRODUCTION Thank you for purchasing this Clarke portable compressor. The unit is powered by a Honda engine, a manual for which, is provided separately. Please refer to that manual for all matters relating to the engine, ...starting and stopping procedures, maintenance etc. -
Page 3: For Your Safety
FOR YOUR SAFETY WARNING As with all machinery, there are certain hazards involved with their operation and use. Exercising respect and caution will considerably lessen the risk of personal injury. However, if normal safety precautions are overlooked, or ignored, personal injury to the operator, or damage to property may result. - Page 4 NEVER allow anyone, not fully familiar with compressors, to use this equipment. • DO NOT alter the engine settings..these settings are set at the factory. Should they need recalibration - consult your Clarke dealer WARNING! DO NOT ATTEMPT TO ALTER ENGINE SPEED SETTINGS...
- Page 5 Fig.1 - 5 -...
-
Page 6: Preparation For Use
F. Air Hose & Air Tool • Attach the air hose to the outlet using an appropriate connector. • Attach the air tool/spray gun to the air hose...If using snap couplings, use a whip end, available from your Clarke dealer. - 6 -... -
Page 7: Starting The Compressor
STARTING THE COMPRESSOR Open the drain cock and allow any condensate to drain compleatly, • The drain cock in located on the bottom of the receiver tank. Close the drain cock. Fully open the bleed valve. Connect the air hose to the air outlet. connect your air tool to the air hose. •... -
Page 8: Maintenance
Compressor oil - 5 litre: Part No. 3050802 In addition to the above, check the engine manual for service schedule. Repairs should only be carried out by a qualified engineer. If problems occur, contact your Clarke dealer. - 8 -... -
Page 9: Pump Parts
PUMP PARTS - 9 -... - Page 10 PUMP PARTS 15ND Description Part No. Screw 014013054 113149015 Lower Cover 113167001 Casing 033027000 Bearing 010053000 Seal 113149008 Front Cover 014013021 Screw 013160010 Flywheel 014005001 Washer 113160011 Screw 014013082 Screw 014005025 Washer 113149009 Rear Cover 012036000 Oil Dipstick 014010044 Screw 113167003 Crankshaft 113150004...
- Page 11 PARTS LIST HS17210-ZE1-822 HS17218-ZE1-821 HS98079-56846 1. HS28442-ZH8-003 2. HS28442-ZH8-003 3. HS28462-ZH8-003 2100177 50mm Pressure Gauge 2000161 Safety Valve Complete 2000192 Drain Cock 2000220 V-Belt 2000078 Pump Complete. 1390085 (MK103) Pulley 2100084 Engine complete 8000055 (GX200QH) Manifold 3-way CBM45469000 Air Receiver 1985150 - 11 -...
-
Page 12: Troubleshooting Chart
Compressor unit Load Genie defective. Have Load Genie serviced or replaced constantly ‘on load’ Contact Clarke Service Load Genie set at a pressure Department higher than the safety valve’s opening pressure. Load Genie leaking. Contact Clarke Service Department Clean / Change filter. - Page 13 Flywheel loose. Tighten flywheel. Unit installed on an unsuitable Move unit to a more solid base. base. Bearings, piston rings or cylinder Contact Clarke Service worn. Department Contact Clarke Service Valve broken. Department Compressor See that sufficient air is supplied to Insufficient ventilation.
- Page 14 Check oil level 2 or 3 minutes after Compressor’s oil Too much oil in compressor. stopping. consumption rising. Contact Clarke Service Leaks around crank case. Department Working temperature of Increase ventilation to air compressor too high because of compressor.
- Page 15 Notes - 15 -...
