  • Page 1: Parts And Service

    REBEL REBEL OPERATION & MAINTENANCE INSTRUCTIONS © 0903...

  • Page 2: Table Of Contents

    Thank you for purchasing this Rebel Air Compressor which is available in two configurations - REBEL 30, fitted with a 24 litre air receiver and REBEL60, fitted with a 50 litre receiver. The REBEL 60 is also available in both 230V and 110V configurations.

  • Page 3: Safety Precautions

    2. DO NOT operate your compressor with any guards removed. 3. Electrical or mechanical repairs should only be carried out by a qualified engineer. If problems occur, contact your Clarke dealer. 4. Before carrying out any maintenance, ensure the pressure is expelled from the air receiver, and the machine is disconnected from the mains supply.

  • Page 4: Electrical Connections

    We recommend that this machine is connected to the mains supply via a Residual Current Device (RCD) If in any doubt, DO NOT attempt any connections or repairs yourself. Consult a qualified electrician, your Clarke dealer, or CLARKE International Service Dep’t on 020 8988 7400 or, e-mail Service@clarkeinternational.com...

  • Page 5: Preparation For Use

    (see Fig. 6 - p.9). Check the oil level is at the correct level on the dipstick, as shown in Fig.1. Where necessary, top up with Clarke SAE40 Compressor Oil (available from your Clarke dealer).
  • Page 6 This operation is completely automatic and does not affect the spraying process in any way. However, should problems develop with the cut-in, cut out settings, please consult your Clarke dealer, or Fig. 3 the Clarke Service Dep’t.

  • Page 7: Shutting Down

    The motor is protected by a Thermal Overload so that if the motor overheats for any reason - the thermal overload will trip, stopping the motor. To restart, allow a period for the motor to cool down, before pressing the Reset Button, shown in Fig.3. SHUTTING DOWN THE COMPRESSOR To shut off the compressor, simply press DOWN on the ON/OFF knob (See Fig.
  • Page 8 If any part of the filter is damaged then you should obtain a replacement. 3. After the first 100 hours use, replace the oil completely using Clarke SAE 40 compressor oil. Thereafter, replace the oil completely after every 500 hours of operation or every 6 months.

  • Page 9: Fault Finding

    FAULT FINDING PROBLEM PROBABLE CAUSE REMEDY The compressor Check the electrical Bad connections. stops and will not connections. start again. Clean and tighten as necessary. Blown fuse Renew/Replace fuse Overload cutout Switch off and wait 5 minutes switch has tripped. before pressing the reset button.

  • Page 10: Specifications

    (This machine may be run continuously) Please note that the details and specifications contained herein, are correct at the time of going to print. However, CLARKE International reserve the right to change specifications at any time without prior notice.Always consult the machines’ data plate.

  • Page 11: Parts Lists And Diagrams

    REBEL 30 No. Description Qty Part No. No. Description Qty Part No. 65 Adapter 1 FN199110220 50 Reservoir FN168Z50000V 66 Pressure Gauge-Res 1 FN330007000 51 Flat Washer FN014005010 67 Adapter 1 FN011017000 52 Drain valve FN022020000 68 Handle 1 FN020121000...
  • Page 12 REBEL 60 No. Description Part No. No. Description Part No. 50 Reservoir FN170018000V 67 Adapter FN011017000 51 Plug FN011008000 68 Pressure Gauge-Line 1 FN330006000 52 Drain valve FN022020000 69 Tube FN046001000 53 Wheel FN020001000 70 Elbow FN011002000 54 Push On Fastener FN015029000 71 Anti-vibration pad FN199575000...
  • Page 13 COMPRESSOR...
  • Page 14 - Gasket Set FN216091001 26 Capacitor (230V) FN009200026 SPARES AND SERVICING Please contact your local dealer/service agent or the Clarke International on: PARTS & SERVICE TEL: 020 8988 7400 PARTS & SERVICE FAX: 020 8558 3622 e-mail as follows: PARTS: Parts@clarkeinternational.com SERVICE: Service@clarkeinternational.com...
